Chapter 1: Product Overview
The NCR CX5 All-in-One POS (7773), powered by Intel’s Apollo Lake System on Chip
(SoC), delivers great performance and low energy cost. The CX5 is a fan-less system
that features a sleek design and provides a wide range of configuration versatility. The
ability to configure with an I/O board that accommodates environments with more USB
devices or an I/O board that accommodates environments with more serial devices
gives customers the flexibility that prevents additional expansion boards or hubs.
The CX5 offers two I/O configurations:
• USB Centric I/O
• Serial Centric I/O
I/O Board Connectors
USBCentric I/O
(Retail)
Serial Centric I/O
(Hospitality)
USB-C to Head 1 1
12VPowered USB 3 1
24VPowered USB 1 1
Serial 1 x RJ50
1 x DB9
4 x RJ12
2 x RJ45
USB3.0 (5V) 2 2
DisplayPort 1 1
