3-74
LED
Diagnostic
LEDs
The
Power
LED
and
HDD
LED
also
function
as
diagnostic
indicators,
defined
below.
Note:
The
c
ell
colors
indicate
the
color
of
the
LED
at
that
particular
time.
Current
System
Operation
Suspect
Component/
Failure
Terminal
State
HDD
LED
Power
LED
Debug
Path
Normal
Operation
N/A
System
ON
OFF
ON
N/A
Normal
Operation
N/A
System
ON
with
HDD
Activity
Flashing
(HDD
Access)
ON
N/A
Normal
Operation
N/A
Unit
in
Suspend
(S3/S4)
ON
Blinking
(1x/sec)
N/A
OFF
wi
th
AC
Present
N/A
OFF,
Not
in
Standby.
External
power
su
pply
is
on
.
ON
OFF
N/A
87
89
