Product
Overview
1-35
DisplayPort
The
I/O
Board
provides
a
2-lane
DisplayPort.
Lanes
2
and
3
of
the
DisplayPort
are
not
connected
internally.
Pin
Signal
Name
1
ML_Lane0
(p)
2
GND
3
ML_Lane0
(n)
4
ML_Lane1
(p)
5
GND
6
ML_Lane1
(n)
7
ML_Lane2
(p)
8
GND
9
ML_Lane2
(n)
10
ML_Lane3
(p)
11
GND
12
ML_Lane3
(n)
13
CONFIG1
14
CONFIG2
15
AUXCH
(p)
16
GND
17
AUXCH(n)
18
Hot
Plug
Detect
19
Return
20
DP_PWR
Note:
DisplayPort
does
not
support
dual-mode
DisplayPort
(DP++).
Use
the
Active
Adapter
DisplayPort
/M
to
HDMI
/F
(NCR
part
number
497-0530701)
if
driving
an
HDMI
display.
48
50
