NCR VOYIX CX5 User Manual

1-28 Product Overview
Integrated I/O
The following are the default I/O ports for the NCR CX5 All-in-One POS (7773) with
Integrated SerialCentric I/O(Hospitality).
Callout Port Name
1 RJ45 Serial
• COM5 (Enhanced UART)
• COM6 (Standard UART)
2 Dual USB 3.0
3 USB12V
4 USB24V
5 24VPower In
6 Status LED
7 USB-C
8 DisplayPort
9 Cash Drawer B
10 Cash Drawer A
11 RJ12 Serial
• COM1 (Enhanced UART)
• COM2 (Standard UART)
• COM3 (Enhanced UART)
• COM4 (Standard UART)
Note: The Integrated SerialCentric I/O(Hospitality) does not include a LANPort.
ALANPort is available on the Motherboard. To connect to a network, refer to
Connecting to a Network on page56.
