2-54 Hardware Installation

Installing the Terminal

This chapter explains how to perform an "Out-of-box" installation of a CX5 configured

with the Base and how to connect optional peripheral devices. The standard items

included in the box are:

• CX5 POS

• Power Supply

• Power Cord

• I/OSecurity Cover

The CX5 comes fully assembled and ready to use. All that is required to install is

connect the AC Power Cord, LAN Cable, and peripheral device cables.

For more information about the CX5 I/O ports, refer to:

• USB Centric I/O (Retail) on page23

• Serial Centric I/O(Hospitality) on page26

Note: The POSLCD has a protective film. After removing the film, the LCD should be

cleaned. For more information, refer to Cleaning the Touchscreen on page82.
