1-30
Product
Overview
Remote
I/OChassis
The
following
are
the
default
I/O
ports
for
the
NCR
CX5
All-in-One
POS
(7773)
Remote
Serial
Centric
I/O
(Hospitality)
Chassis
.
Callout
Port
Name
1
RJ12
Serial
•
COM1
(Enhanced
UART)
•
COM2
(Standard
UART)
•
COM3
(Enhanced
UART)
•
COM4
(Standard
UART)
2
Cash
Drawer
A
3
Cash
Drawer
B
4
DisplayPort
5
LANIn
Note:
Connect
to
Ethernet
Network
6
LAN
Out
Note:
Connect
to
the
CXHead
7
USB-C
8
LED
9
24VPower
In
10
USB24V
11
USB12V
12
Dual
USB
3.0
13
RJ45
Serial
•
COM5
(Enhanced
UART)
•
COM6
(Standard
UART)
43
45
