EN
Mounting the charger
NOTICE! Damage hazard
Before drilling any holes, ensure that no electrical cables or other parts of the vehicle can be damaged by
drilling, sawing and filing.
1. Ensure that the vehicle's engine and the battery chargers are switched off.
2. Screw the charger to the mounting surface.
fig. on page2
Connecting the charger
WARNING! Electrocution hazard
Observe the recommended cable cross sections, cable lengths and fuse.
CAUTION! Fire hazard
Place the fuses near the batteries to protect the cable from short circuits and possible burning.
NOTICE! Damage hazard
Do not reverse the polarity.
Observe the following instructions when connecting the charger:
• Use suitable measuring instruments:
• Multimeter with DC voltage measurement, 200 V or autoscale
• Amperometric clamp with direct measurement (100 A scale or higher)
• Use cables with a cross section of 6 mm.
• Always connect the charger before connecting the batteries.
• Do not use ferrules. Strip the cable ends as follows:
• Signal cable: 12 mm (0.5 mm²… 1.5 mm²)
• Charging cable: 15 mm
Make the required connections to the charger.
9 Configuration
NOTICE! Damage hazard
Use a small screwdriver to carefully move the DIP switches to the required position.
Setting the charging program
NOTICE! Damage hazard
Only use batteries that are suitable for the specified charging voltage.
11
