Service Manual CP-785F
-59-
LOC PART NAME PART Code PART Description Remark
J090 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J091 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J093 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J094 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J096 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J097 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J098 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J099 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J100 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J102 R M-OXIDE FILM RS01Z569J- 1W 5.6 OHM J (TAPPING)
J103 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J104 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J302 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J303 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J500 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J601 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J602 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J603 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
J604 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
JPA1 JACK PIN BOARD 4859109250 PH-JB-9614A
JPA3 JACK PIN BOARD 4859111750 PH-JB-9515
L101 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
L350 COIL PEAKING 5CPZ109M04 1UH 10.5MM M (LAL04TB)
L381 COIL PEAKING 5CPZ109M04 1UH 10.5MM M (LAL04TB)
L401 COIL H-LINEARITY 58H0000047 TRL-190D
L402 COIL CHOKE 58C7070085 TLN-3062A
L500 COIL PEAKING 5CPZ120K02 12UH K (AXIAL 3.5MM)
L501 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
L502 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
L510 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
L511 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
L512 COIL PEAKING 5CPZ100K02 10UH K (AXIAL 3.5MM)
L601 COIL PEAKING 5CPZ479K02 4.7UH K (AXIAL 3.5MM)
L602 COIL PEAKING 5CPZ479K02 4.7UH K (AXIAL 3.5MM)
L603 COIL PEAKING 5CPZ479K02 4.7UH K (AXIAL 3.5MM)
L650 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
L801 COIL BEAD 5MC0000100 HC-3550
L802 COIL CHOKE 58CX430599 AZ-9004Y 940K TP
L803 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
LF801 FILTER LINE 5PLF24A1 LF-24A1
N001 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
N002 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
N003 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
N004 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
N401 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
N402 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
