NEC DTE-29U1TH - Page 61

Service Manual CP-785F
-60-
LOC PART NAME PART Code PART Description Remark
N403 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
N404 TERM PIN 4857417500 DA-IB0214(D2.3/DY PIN)
P401 CONNECTOR 4850705N19 YBNH250+YBNT250+ULW=400
P501 CONNECTOR 4850705N14 YBNH250-05+YBNH250+ULW500
P601 CONN WAFER 485923172S YW025-04 (STICK)
P602 CONN WAFER 485923522S YW025-09 (STICK)
P904 CONN WAFER 4859238620 YPW500-02
PWC1 CORD POWER AS 4859903010 SAA LP-15A YFH800 2.6M
Q101 TR TKTC3198Y- KTC3198Y
Q401 HEAT SINK ASS‘Y PTG2SW7609 TST2009DH1 + 7174300811 2SD-2553 ==>COMPABLE
Q402 TR TKTC3229 KTC3229
Q501 TR TKTA1266Y- KTA1266Y (TP)
Q502 TR TKTC3198Y- KTC3198Y
Q503 TR TKTC3198Y- KTC3198Y
Q504 TR TKTC3198Y- KTC3198Y
Q505 TR TKTA1266Y- KTA1266Y (TP)
Q506 TR TKTC3198Y- KTC3198Y
Q507 TR TKTC3198Y- KTC3198Y
Q508 TR TKTC3198Y- KTC3198Y
Q509 TR TKTC3198Y- KTC3198Y
Q601 TR TKTA1266Y- KTA1266Y (TP)
Q807 TR TKTC3198Y- KTC3198Y
Q808 TR TKTC3198Y- KTC3198Y
Q809 TR TKTC3198Y- KTC3198Y
Q810 TR TKTC3198Y- KTC3198Y
Q811 TR TKTC3198Y- KTC3198Y
Q822 TR TKTC3205Y- KTC3205Y (TP)
R101 R CARBON FILM RD-AZ473J- 1/6 47K OHM J
R102 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J
R103 R CARBON FILM RD-AZ123J- 1/6 12K OHM J
R104 R CARBON FILM RD-AZ104J- 1/6 100K OHM J
R105 R CARBON FILM RD-AZ392J- 1/6 3.9K OHM J
R106 R CARBON FILM RD-AZ101J- 1/6 100 OHM J
R107 R CARBON FILM RD-AZ101J- 1/6 100 OHM J
R115 R CARBON FILM RD-AZ682J- 1/6 6.8K OHM J
R116 R CARBON FILM RD-AZ222J- 1/6 2.2K OHM J
R120 R CARBON FILM RD-AZ101J- 1/6 100 OHM J
R310 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
R311 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
R331 R M-OXIDE FILM RS01Z331J- 1W 330 OHM J (TAPPING)
R340 R CARBON FILM RD-4Z473J- 1/4 47K OHM J
R350 R METAL FILM RN-4Z1501F 1/4 1.50K OHM F
R351 R METAL FILM RN-4Z1501F 1/4 1.50K OHM F
R370 R CARBON FILM RD-4Z159J- 1/4 1.5 OHM J
R393 R CARBON FILM RD-2Z279J- 1/2 2.7 OHM J
R394 R CARBON FILM RD-AZ272J- 1/6 2.7K OHM J
