SYSTEM CONFIGURATION GUIDE – NEC Express5800R120f-1E
NEC Corporation Revision 6.0 – July 16, 2015 10
Server Configuration
1 Base Models
Product Name / Description
Part Number
NEC Express5800/R120f-1E Server
no processor, no RAM, no HDD, no ODD, no LOM Card
Including : 1 x 460 Watt 80 PLUS® Platinum Power Supply Unit, Front Bezel, 2.5-inch
Drive Cage, EXPRESSBUILDER DVD
N8100-2249F
NEC Express5800/R120f-1E Server
no processor, no RAM, no HDD, no ODD, no LOM Card
Including : 1 x 800 Watt 80 PLUS® Platinum Power Supply Unit, Front Bezel, 2.5-inch
Drive Cage, EXPRESSBUILDER DVD
N8100-2250F
NEC Express5800/R120f-1E Server
no processor, no RAM, no HDD, no ODD, no LOM Card
Including : 1 x 800 Watt 80 PLUS® Titanium Power Supply Unit, Front Bezel, 2.5-inch
Drive Cage, EXPRESSBUILDER DVD
N8100-2251F
NOTE:
 The base model must be ordered with a processor kit, a memory kit, and a LOM card.
 Use the NEC Power Supply Selector to select appropriate size for power units. For details, please
visit the NEC website at:
http://www.nec.com/en/global/prod/express/collateral/tools/PowerSelector_G01.xls
2 Processors and Heat Sink
Available sockets: 2
Product Name / Description
Part Number
Processors
1 Processor
Required
Xeon E5-2603 v3 Processor Kit
Intel® Xeon ® Processor E5-2603 v3 (1.60 GHz, 6C/6T, 15 MB)
N8101-768F
Xeon E5-2620 v3 Processor Kit
Intel® Xeon ® Processor E5-2620 v3 (2.40 GHz, 6C/12T, 15 MB)
N8101-770F
Xeon E5-2630 v3 Processor Kit
Intel® Xeon ® Processor E5-2630 v3 (2.40 GHz, 8C/16T, 20 MB)
N8101-934F
Xeon E5-2630L v3 Processor Kit
Intel® Xeon ® Processor E5-2630L v3 (1.80 GHz, 8C/16T, 20 MB)
N8101-935F
Xeon E5-2640 v3 Processor Kit
Intel® Xeon ® Processor E5-2640 v3 (2.60 GHz, 8C/16T, 20 MB)
N8101-773F
Xeon E5-2650 v3 Processor Kit
Intel® Xeon ® Processor E5-2650 v3 (2.30 GHz, 10C/20T, 25 MB)
N8101-936F
Xeon E5-2650L v3 Processor Kit
Intel® Xeon ® Processor E5-2650L v3 (1.80 GHz, 12C/24T, 30 MB)
N8101-775F
Xeon E5-2660 v3 Processor Kit
Intel® Xeon ® Processor E5-2660 v3 (2.60 GHz, 10C/20T, 25 MB)
N8101-776F
Heat Sink
1st
Processor Heat Sink
For 1
st
Processor
(Standard)
2nd
Processor Heat Sink
For 2
nd
Processor, including cooling fan kit
N8101-901F
NOTE:
 Minimum one processor kit from above must be installed.
 The processors must be the same to configure dual processor system.
 The 32-bit operating systems, Microsoft Windows Server 2008 and Red Hat Enterprise Linux 6 (x86),
are supported only on Xeon E5-2603 v3, E5-2620 v3, Xeon E5-2630 v3,.Xeon E5-2630L v3, and
Xeon E5-2640 v3 systems.
