NEC Express5800/R120f-1E User Manual

SYSTEM CONFIGURATION GUIDE – NEC Express5800R120f-1E
NEC Corporation Revision 6.0 – July 16, 2015 30
Supported PCI Cards and Installable Slots
Standard Riser Card
Slots
Part Number
Product Name
#1A
#1B
#1D
N8104-155F
Dual Port 10GBASE-T LOM Card
-
1
-
N8104-156F
Dual Port 10G-SFP + Dual Port 1000BASE-T LOM
Card
-
1
-
N8104-154F
Quad Port 1000BASE-T LOM Card
-
1
-
N8103-176
RAID Controller (1 GB, RAID 0/1)
1
-
-
N8103-177
RAID Controller (1 GB, RAID 0/1/5/6)
1
-
-
N8103-178
RAID Controller (2 GB,RAID 0/1/5/6)
1
-
-
N8103-179
RAID Controller (2 GB,RAID 0/1/5/6)
-
-
1
N8118-01
PCIe SSD Adapter 365GB
-
-
1
N8190-158A
Fibre Channel Controller (2ch)
-
-
1
N8190-157A
Fibre Channel Controller
-
-
1
N8104-147
Dual Port InfiniBand Adapter
-
-
1
N8104-146
Single Port InfiniBand Adapter
-
-
1
N8103-184
SAS Controller
-
-
1
N8104-153
Dual Port 10GBASE-T Adapter
-
-
1
N8104-149
10GBASE SFP+ Adapter (SFP+/2ch)
-
-
1
N8104-148
Dual Port 10GBASE SFP+ Adapter (SFP+/2ch)
-
-
1
N8190-160
Fibre Channel Controller (2ch)
-
-
1
N8190-159
Fibre Channel Controller
-
-
1
N8103-142
SAS Controller
-
-
1
N8104-152
Quad Port 1000BASE-T Adapter
-
-
1
N8104-145
Dual Port 1000BASE-T Adapter
-
-
1
N8104-151
Dual Port 1000BASE-T Adapter
-
-
1
N8104-150
1000BASE-T Adapter
-
-
1
N8117-01A
Serial Port Adapter
-
-
1
NOTE:
 The number in the table shows the population priority (recommendation).
 For the configuration limitation for VMware ESXi, refer to the following documents.
VMware ESXi5.1
https://www.vmware.com/pdf/vsphere5/r51/vsphere-51-configuration-maximums.pdf
VMware ESXi5.5
https://www.vmware.com/pdf/vsphere5/r55/vsphere-55-configuration-maximums.pdf
VMware ESXi6.0
https://www.vmware.com/pdf/vsphere6/r60/vsphere-60-configuration-maximums.pdf
