NEC Express5800/R120f-1E User Manual

SYSTEM CONFIGURATION GUIDE – NEC Express5800R120f-1E
NEC Corporation Revision 6.0 – July 16, 2015 3
Technical Specification
Key Features
 High performance with the latest Intel® Xeon® processor E5-2600 v3 Product Family
 Up to 512 GB of high speed DDR4 memory
 High energy efficiency with power capping feature and 80 PLUS® Platinum power supply
 Full manageability by integrated EXPRESSSCOPE Engine 3
Specification
(1 / 2)
Model
R120f-1E
Processor
Type
Intel® Xeon®
processor
E5-2603 v3
Intel® Xeon®
processor
E5-2620 v3
Intel® Xeon®
processor
E5-2630 v3
Intel® Xeon®
processor
E5-2630L v3
Clock speed
1.60GHz
2.40 GHz
1.80 GHz
Number of Processors
1 or 2
Cache
15 MB
20 MB
Cores and Threads
6C-6T
6C-12T
8C-16T
Chipset
Intel® C612 Chipset
Memory
Type
DDR4-2133 Registered DIMM
DDR4-2133 Load Reduced DIMM
Standard Capacity
0 GB
Maximum Capacity
512 GB (16 x 32 GB)
Memory protection
ECC, x4 SDDC, Memory Mirroring, Memory Lockstep, Memory
Sparing
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SAS HDD : 14.4 TB (8 x 1.8 TB)
SATA HDD : 16 TB (8 x 2 TB)
SAS SSD : 3.2 TB ( 8 x 400 GB)
SATA SSD : 6.4 TB (8 x 800 GB)
Disk Controller
SATA : 6Gb/s (Integrated)
SAS: 12 Gb/s (Optional)
RAID
SATA : RAID 0/1/5/6/10/50/60 (Optional)
SAS : RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
8
Expansion Slots
Standard
Total: 3 slots available
1 PCIe 3.0 x8 (x8 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Optional Riser Card
(N8116-39)
Total: 4 slots available
2 PCIe 3.0 x8 (x8 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Optional Riser Card
(N8116-33)
Total: 4 slots available
2 PCIe 3.0 x16 (x16 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1600 x 1200 / 16.7M
1

NEC Express5800/R120f-1E Specifications

General

Brand	NEC
Model	Express5800/R120f-1E
Category	Server
Language	English
