SYSTEM CONFIGURATION GUIDE – NEC Express5800R120f-1E
NEC Corporation Revision 6.0 – July 16, 2015 4
Model
R120f-1E
Interfaces
2 x VGA (15-pin mini D-sub, 1 x front, 1 x rear)
1 x Serial (9-pin mini D-sub, RS232-C, Serial A, 1 x rear)
4 x USB3.0 (2 x front, 2 x rear)
1 x Management LAN connector (RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Standard, non-hot plug
Redundant Power Supply
Optional, hot plug
Power Supply
1-2 x 460 Watt or 800 Watt 80 PLUS® Platinum certified hot plug
PSU, or 800 Watt 80 PLUS® Titanium certified hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power
Consumption
(Max. Config, Idling)
193 VA
/ 191 Watt
192 VA
/ 191 Watt
186 VA
/ 184 Watt
188 VA
/ 187 Watt
(Max. Config,
Operating)
457 VA
/ 454 Watt
555 VA
/ 551 Watt
568 VA
/ 564 Watt
500 VA
/ 497Watt
Acoustical Noise
(Sound Pressure
Level)
2
Max. Config, Idling
45.2 dB
45.2 dB
Max. Config, Operating
53.0 dB
52.0 dB
Dimensions (W x D x H )
439.8 x 722.0 x 43.4 mm / 17.3 x 28.4 x 1.7 in (1U)
Weight (Minimum / Maximum)
14.6 kg / 21.0 kg, 32.18 lbs. / 46.29 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, UL, CB, CE, BSMI, UL(Mexico), KC, CCC, RCM, RoHS,
WEEE
Operating Systems
Microsoft® Windows Server® 2008 Standard (x86)
Microsoft® Windows Server® 2008 Enterprise (x86)
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Datacenter
Microsoft® Windows Server® 2012 R2 Standard
Microsoft® Windows Server® 2012 R2 Datacenter
Red Hat Enterprise Linux 6.5 or later (x86)
3
Red Hat Enterprise Linux 6.5 or later (x86_64)
3
Red Hat Enterprise Linux 7.1 or later
3
VMware ESXi™ 5.1 Update 2
VMware ESXi™ 5.5 Update 2
VMware ESXi™ 6.0
1
Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
2
Noise emission was measured at the bystander positions in accordance with ISO 7779. The actual value may
vary by the operating environment.
3
For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html
(2 / 2)
Model
R120f-1E
Processor
Type
Intel® Xeon®
processor
E5-2640 v3
Intel® Xeon®
processor
E5-2650 v3
Intel® Xeon®
processor
E5-2650L v3
Intel® Xeon®
processor
E5-2660 v3
Clock speed
2.60 GHz
2.30 GHz
1.80 GHz
2.60 GHz
Number of Processors
1 or 2
Cache
20 GB
25 MB
30 MB
25 MB
Cores and Threads
8C-16T
10C-20T
12C-24T
10C-20T
Chipset
Intel® C612 Chipset
