SYSTEM CONFIGURATION GUIDE – NEC Express5800R120f-1E
NEC Corporation Revision 6.0 – July 16, 2015 5
Model
R120f-1E
Memory
Type
DDR4-2133 Registered DIMM
DDR4-2133 Load Reduced DIMM
Standard Capacity
0 GB
Maximum Capacity
512 GB (16 x 32 GB)
Memory protection
ECC, x4 SDDC, Memory Mirroring, Memory Lockstep, Memory
Sparing
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SAS HDD : 14.4 TB (8 x 1.8 TB)
SATA HDD : 16 TB (8 x 2 TB)
SAS SSD : 3.2 TB ( 8 x 400 GB)
SATA SSD : 6.4 TB (8 x 800 GB)
Disk Controller
SATA : 6Gb/s (Integrated)
SAS: 12 Gb/s (Optional)
RAID
SATA : RAID 0/1/5/6/10/50/60 (Optional)
SAS : RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
Optical Drive Bays
1
Disk Drive Bays
8
Expansion Slots
Standard
Total: 3 slots available
1 PCIe 3.0 x8 (x8 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Optional Riser Card
(N8116-39)
Total: 4 slots available
2 PCIe 3.0 x8 (x8 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Optional Riser Card
(N8116-33)
Total: 4 slots available
2 PCIe 3.0 x16 (x16 connector)
1 PCIe 3.0 x8 (x8 connector) dedicated RAID slot
1 PCIe 3.0 x8 (x8 connector) flexible integrated NIC slot
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1600 x 1200 / 16.7M
1
Interfaces
2 x VGA (15-pin mini D-sub, 1 x front, 1 x rear)
1 x Serial (9-pin mini D-sub, RS232-C, Serial A, 1 x rear)
4 x USB3.0 (2 x front, 2 x rear)
1 x Management LAN connector (RJ-45, 1 x rear)
Server Management
EXPRESSSCOPE Engine 3
Redundant Fan
Standard, hot plug
Redundant Power Supply
Optional, hot plug
Power Supply
1-2 x 460 Watt or 800 Watt 80 PLUS® Platinum certified hot plug
PSU, or 800 Watt 80 PLUS® Titanium certified hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power
Consumption
(Max. Config, Idling)
191 VA
/ 189 Watt
194 VA
/ 192 Watt
185 VA
/ 184 Watt
194 VA
/ 193 Watt
(Max. Config,
Operating)
602 VA
/ 598 Watt
649 VA
/ 645 Watt
540 VA
/ 537 Watt
658 VA
/ 653 Watt
Acoustical Noise
(Sound Pressure
Level)
3
Max. Config, Idling
45.2 dB
45.2 dB
45.2 dB
45.2 dB
Max. Config, Operating
53.8 dB
54.0 dB
55.3 dB
54.0 dB
Dimensions (W x D x H )
439.8 x 722.0 x 43.4 mm / 17.3 x 28.4 x 1.7 in (1U)
Weight (Minimum / Maximum)
14.6 kg / 21.0 kg, 32.18 lbs. / 46.29 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, UL, CB, CE, BSMI, UL(Mexico), KC, CCC, RCM, RoHS,
WEEE
