1-7
Quick Installation –continued
Remove Monitor Stand for Mounting
To prepare the monitor for alternate mounting purposes:
1.Disconnect all cables.
2.Place monitor face down on a non-abrasive
surface (Figure R.1).
3.Remove the 4 screws connecting the monitor
to the stand and lift off the stand assembly
(Figure R.1). The monitor is now ready for
mounting in an alternate manner.
4.Connect the AC cord and signal cable to the
back of the monitor.
5. Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method.
6.This LCD monitor is designed for use with a flexible arm.
Please use the attached screws (4pcs) as shown in the picture when
installing.
To meet fhe safety requirements, the monitor must be mounted to an arm
which guaranties the necessary stability under consideration of the weight
of the monitor.
The LCD monitor shall only be used with an approved arm (e.g. GS mark).
Figure R.1
Non-abrasive surface
Replace screws.
5
