NEC MultiSync LCD1920NX User Manual

REPLACEMENT PARTS LIST
The com
p
onents s
p
ecified for Model LCD1920NX
(
A
)
SYMBOL
Part No for AmTRAN
Part No for NMV DESCRIPTION
*** ICS ***
IC01 0430-8000-3846 79PZ0154 IC AD9884AKS-140 SMD 128P
IC02 0430-7007-4939 79PZ0151 IC AM121-2 SMD 160 PIN
IC03 0430-7000-6015 79PZ0148 IC TLC2933IPWR SMD 14PIN
IC04 0430-7007-7040 79PZ0152 IC MTV118P-49 16PIN
IC06 0430-1004-1035 79PZ0141 IC 74F153SC SMD 16PIN
IC07X 0990-0000-4400 79PZ0156 S/W RDT191S EEPROM(IC07)
IC08 0430-6002-0007 79PZ0146 IC LD1117S-ADJ SMD
IC09 0430-1003-3635 79PZ0138 IC 74LCX245MTCX SMD 20PIN
IC11 0430-7007-9738 79PZ0153 IC SII153BCT100 SMD 100PI
IC12 0430-0000-6004 79PZ0133 IC CD4049UBM SMD 16PIN
IC14 0430-3001-1011 79PZ0144 IC AT24C02N-10SC-2.7 SMD
IC15 0430-1003-0035 79PZ0137 IC DM74LS14MX SMD 14PIN
IC16 0430-0000-8035 79PZ0134 IC MM74HC4053WMX SMD 16PI
IC17 0430-1004-0635 79PZ0140 IC DM74LS86 SMD 14PIN
IC18 0420-1001-3601 79PZ0132 POWER MOS IRF7304 SMD 8PI
IC19 0420-1001-3601 79PZ0132 POWER MOS IRF7304 SMD 8PI
IC20 0430-4000-2004 79PZ0145 IC LM339M SMD-14 T
IC21 0420-1001-3601 79PZ0132 POWER MOS IRF7304 SMD 8PI
IC22 0420-1001-3601 79PZ0132 POWER MOS IRF7304 SMD 8PI
IC23 0430-1000-7035 79PZ0135 IC 74HC14 SMD 14PIN
IC24X 0990-0000-4500 79PZ0157 S/W RDT191S EEPROM(IC24)
IC25X 0990-2000-4406 79PZ0161 SOFTWARE LCD1920NX CPU:NE
IC26 0430-3000-2017 79PZ0143 IC MP24LC21AT/SN SMD 8PIN
IC27 0430-1000-8035 79PZ0136 IC MM74HC74AMX SMD 14PIN
IC28 0430-1000-7035 79PZ0135 IC 74HC14 SMD 14PIN
IC29 0430-1003-8635 79PZ0139 IC MM74HC08 SMD 14PIN
IC30 0430-1005-2035 79PZ0142 IC 74VHC32 SMD 14PIN
IC31 0430-6002-5051 79PZ0147 IC AMC7588-ADJ SMD 3PIN
IC33 0430-1000-8035 79PZ0136 IC MM74HC74AMX SMD 14PIN
IC34 0430-1003-8635 79PZ0139 IC MM74HC08 SMD 14PIN
IC36 0430-7003-7650 79PZ0149 IC THC63LVDM83A SMD 56PIN
IC37 0430-7003-7650 79PZ0149 IC THC63LVDM83A SMD 56PIN
Q30 0430-7004-4319 79PZ0150 IC PST994D TO-92 3PIN D=4
*** TRANSISTORS ***
Q01 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q02 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q03 0410-5000-2610 79PZ0131 TRANSISTOR MMBT3906LT1 SM
Q04 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q05 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q06 0410-0000-2106 79PZ0129 TRANSISTOR 2SA673AC TO-92
8-1
