SYMBOL
Part No for AmTRAN
Part No for NMV DESCRIPTION
Q08 0410-0000-2106 79PZ0129 TRANSISTOR 2SA673AC TO-92
Q09 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q10 0410-0000-2106 79PZ0129 TRANSISTOR 2SA673AC TO-92
Q11 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q12 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q13 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q14 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q16 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q19 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
Q25 0410-5000-1610 79PZ0130 TRANSISTOR MMBT3904LT1 SM
*** DIODES ***
D01 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
D02 0390-5001-9293 79PZ0124 DUAL SURFACE DIODES BAV99
D05 0390-5001-9293 79PZ0124 DUAL SURFACE DIODES BAV99
D06 0390-5001-9293 79PZ0124 DUAL SURFACE DIODES BAV99
D07 0390-5001-9293 79PZ0124 DUAL SURFACE DIODES BAV99
D08 0390-5001-9293 79PZ0124 DUAL SURFACE DIODES BAV99
D09 0390-5001-8293 79PZ0123 DUAL SURFACE DIODES BAV70
D11 0400-0541-2012 79PZ0128 ZENER RLZ5.6B 5.45V~5.73V
D115 0390-5000-4202 79PZ0122 GEN. DIODE 1N4004F T
D116 0390-6000-1012 79PZ0125 SCHOTTKY DIODE 11DQ06 T
D12 0400-0541-2012 79PZ0128 ZENER RLZ5.6B 5.45V~5.73V
D13 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
D14 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
D15 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
D17 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
D18 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
D19 0390-6000-9172 79PZ0126 SCHOTTKY DIODE SB340 T
D20 0390-6000-9172 79PZ0126 SCHOTTKY DIODE SB340 T
D24 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
D26 0390-5001-8293 79PZ0123 DUAL SURFACE DIODES BAV70
D27 0390-5001-9293 79PZ0124 DUAL SURFACE DIODES BAV99
D28 0390-5001-9293 79PZ0124 DUAL SURFACE DIODES BAV99
D31 0390-5000-1053 79PZ0121 GEN. DIODE 1N4148 SMD
LED01 0440-5000-0020 79PZ0155 LED L-59GYW 5
ZD03 0400-0511-2000 79PZ0127 ZENER 5C3 5.1-5.3V 1/2W
ZD04 0400-0511-2000 79PZ0127 ZENER 5C3 5.1-5.3V 1/2W
*** RELAYS & SWITCHES ***
SW1 0220-7020-0167 79PZ0109 SW TACTILE 6*6MM 4P
SW2 0220-7020-0167 79PZ0109 SW TACTILE 6*6MM 4P
SW3 0220-7020-0167 79PZ0109 SW TACTILE 6*6MM 4P
SW4 0220-7020-0167 79PZ0109 SW TACTILE 6*6MM 4P
SW5 0220-7020-0167 79PZ0109 SW TACTILE 6*6MM 4P
*** PWB ASSYS ***
DISBD 3190-0032-0156 79PZ0013 LCD DISPLAY BD ASS'Y
8-2
