7-11
R_OUT0_O
52 O Output Color Red Odd Pixel (right pixel)
R_OUT1_O
53 O Output Color Red Odd Pixel (right pixel)
R_OUT2_O
54 O Output Color Red Odd Pixel (right pixel)
R_OUT3_O
55 O Output Color Red Odd Pixel (right pixel)
VDD
56 Power Supply
R_OUT4_O
57 O Output Color Red Odd Pixel (right pixel)
R_OUT5_O
58 O Output Color Red Odd Pixel (right pixel)
R_OUT6_O
59 O Output Color Red Odd Pixel (right pixel)
R_OUT7_O
60 O Output Color Red Odd Pixel (right pixel)
GND
61 Ground
G_OUT0_E
62 O Output Color Green Even Pixel (left pixel)
G_OUT1_E
63 O Output Color Green Even Pixel (left pixel)
G_OUT2_E
64 O Output Color Green Even Pixel (left pixel)
G_OUT3_E
65 O Output Color Green Even Pixel (left pixel)
G_OUT4_E
66 O Output Color Green Even Pixel (left pixel)
VDD
67 Power Supply
G_OUT5_E
68 O Output Color Green Even Pixel (left pixel)
G_OUT6_E
69 O Output Color Green Even Pixel (left pixel)
G_OUT7_E
70 O Output Color Green Even Pixel (left pixel)
GND
71 Ground
GND
72 Ground
G_OUT0_O
73 O Output Color Green Odd Pixel (right pixel)
G_OUT1_O
74 O Output Color Green Odd Pixel (right pixel)
G_OUT2_O
75 O Output Color Green Odd Pixel (right pixel)
G_OUT3_O
76 O Output Color Green Odd Pixel (right pixel)
VDD
77 Power Supply
G_OUT4_O
78 O Output Color Green Odd Pixel (right pixel)
G_OUT5_O
79 O Output Color Green Odd Pixel (right pixel)
G_OUT6_O
80 O Output Color Green Odd Pixel (right pixel)
G_OUT7_O
81 O Output Color Green Odd Pixel (right pixel)
GND
82 Ground
GND
83 Ground
B_OUT0_E
84 O Output Color Blue Even Pixel (left pixel)
B_OUT1_E
85 O Output Color Blue Even Pixel (left pixel)
B_OUT2_E
86 O Output Color Blue Even Pixel (left pixel)
B_OUT3_E
87 O Output Color Blue Even Pixel (left pixel)
B_OUT4_E
88 O Output Color Blue Even Pixel (left pixel)
B_OUT5_E
89 O Output Color Blue Even Pixel (left pixel)
B_OUT6_E
90 O Output Color Blue Even Pixel (left pixel)
VDD
91 Power Supply
VDD
92 Power Supply
B_OUT7_E
93 O Output Color Blue Even Pixel (left pixel)
GND
94 Ground
B_OUT0_O
95 O Output Color Blue Odd Pixel (right pixel)
B_OUT1_O
96 O Output Color Blue Odd Pixel (right pixel)
B_OUT2_O
97 O Output Color Blue Odd Pixel (right pixel)
B_OUT3_O
98 O Output Color Blue Odd Pixel (right pixel)
VDD
99 Power Supply
B_OUT4_O
100 O Output Color Blue Odd Pixel (right pixel)
B_OUT5_O
101 O Output Color Blue Odd Pixel (right pixel)
B_OUT6_O
102 O Output Color Blue Odd Pixel (right pixel)
B_OUT7_O
103 O Output Color Blue Odd Pixel (right pixel)
GND
104 Ground
R_IN00
105 I Channel A Data Input Color Red (LSB)
R_IN01
106 I Channel A Data Input Color Red
R_IN02
107 I Channel A Data Input Color Red
R_IN03
108 I Channel A Data Input Color Red
VDD
109 Power Supply
R_IN04
110 I Channel A Data Input Color Red
