English−82
Product Specications
LCD Module
Pixel Pitch:
Resolution:
Color:
Brightness*
6
:
Contrast Ratio:
Viewing Angle:
86”/217.43 cm diagonal
0.494 mm
3840 x 2160
Over 1073 million colors (depending on display card used)
500 cd/m
2
(max.)
1200:1
89° (typ) @ CR>10
Frequency Horizontal:
Vertical:
15 - 135 kHz (HDMI)/22 - 264 kHz (DisplayPort1)/22 - 134 kHz (DisplayPort2)
23 - 76 Hz
Pixel Clock 25 - 600 MHz (HDMI)
25 - 2380 MHz (DisplayPort1)
25 - 570 MHz (DisplayPort2)
Viewable Size 1895.04 x 1065.96 mm
Input/Output Signal
DisplayPort DisplayPort Connector Digital RGB DisplayPort (Up to 7680 x 4320 (60 Hz)*
1
, HDCP 1.3/2.2)
HDMI HDMI Connector Digital YUV
Digital RGB
HDMI (Up to 4096 x 2160 (60 Hz)*
1
, HDCP 1.4/2.2)
Audio terminal
AUDIO Input DisplayPort Connector Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
HDMI Connector Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
AUDIO
Output
Stereo Mini Jack Analog Audio Stereo L/R 0.5 Vrms
HDMI Connector (ARC*
2
) Digital Audio PCM 32, 44.1, 48 kHz (16/20/24 bit)
Speaker Output External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10 W + 10 W (Stereo)
Control RS-232C In:
LAN:
Remote IN:
9 Pin D-sub
RJ-45 10 BASE-T/100 BASE-TX x 2
Stereo Mini Jack 3.5 mm Ø
USB USB-A USB 2.0 Downstream port, DC 5 V/500 mA (max.)
USB-B USB 2.0 Upstream port
SERVICE Power supply port, DC 5 V/2 A (max.)
Firmware update port
Power Supply 6.6 - 2.6 A @ AC 100 - 240 V 50/60 Hz
Power
Consumption
Normal Operation*
5
:
Energy Saving Mode*
5
(LED glowing amber):
Energy Saving Mode*
5
(LED blinking amber):
Approx. 320 W
2 W or less
0.5 W or less
Operational Environment Temperature*
3
:
Humidity:
Altitude:
0 - 40 °C / 32 - 104 °F
20 - 80 % (without condensation)
3000 m or less (Brightness may decrease with altitude)
Storage Environment Temperature:
Humidity:
–20 - 60 °C / –4 - 140 °F
10 - 80 % (without condensation) / 90 % - 3.5 % x (Temp - 40 °C) regarding over 40 °C
Dimension*
4
1927.6 (W) x 1099.1 (H) x 88.4 (D) mm/75.89 (W) x 43.27 (H) x 3.48 (D) inches (with handle)
1927.6 (W) x 1099.1 (H) x 83.2 (D) mm/75.89 (W) x 43.27 (H) x 3.28 (D) inches (without handle)
Weight Approx. 47.9 kg (105.6 lbs)
Tilt Angle ±15°
Mounting interface 600 mm x 400 mm (M8, 4 Holes)
Power supply for Option Board 12 V/5.5 A (max.)
Power supply for Raspberry Pi Compute Module 12 V/1.67 A (max.)
Power supply for Option Board and Raspberry Pi Compute Module 12 V/5.5 A (max.)
Technical specications are subject to change without notice.
*
1
: Compressed image.
*
2
: HDMI IN1 only.
*
3
: When you use Option Board accessories, please contact your supplier for detailed information.
*
4
: Measurements are of the monitor only and do not include removable parts that protrude.
*
5
: Without any option, with factory settings.
*
6
: The Brightness level changes depending on the input settings, picture settings, installation environment, and individual product characteristics.
The overall Brightness decreases as the product ages due to deterioration over time. It does not maintain a permanent brightness level throughout the product’s life.
