English−27
Chapter 3 Connections
This Chapter Includes:
> “Wiring Diagram” on page 28
> “Connecting to a Personal Computer” on page 29
> “Connecting to a Media Device with HDMI” on page 29
> “HDMI-CEC Command” on page 31
> “Internal Video Sources” on page 33
> “Connecting a USB Device” on page 34
• Do not connect or disconnect cables when turning on the monitor’s main power or other external equipment’s power
as this may result in loss of image.
• Do not use an attenuating (built-in resistor) audio cable. Using an audio cable with a built-in resistor will lower the
sound level.
• Turn off the device’s power before connecting it to the monitor.
• Refer to the device’s user manual for available connection types and instructions for the device.
• We recommend turning off the monitor’s main power before connecting or disconnecting a USB storage device to avoid data
corruption.
