English−25

1
2
4
3
5
6 7
@
#
8
$
&
q
(
-
!
9
0
%
^
*
)
e
=
w
 The buttons with no explanation are not used
with your monitor model.
Some Remote Control buttons are used for
CEC (Consumer Electronics Control). The CEC
buttons are different based on whether the
current CEC setting is [MODE1] or [MODE2].
Please see page 32.
1

POWER ON resumes full power from low power mode.
STANDBY puts the monitor in low power mode.
See page 36.
2

Immediately changes the input to the one on the button
names.
The button names reect the factory preset name for the
input.
3

For use when an Option Board is installed. See page 23.
The function depends on which Option Board is installed in the monitor.
4

Press the buttons to set and change passwords, change the
channel and set the REMOTE ID. See page 61.
5

Makes selections.
For use with an Option Board. The function depends on
which Option Board is installed in the monitor.
6

Shows/Hides the information OSD. See page 41.
Unlocks the remote control’s buttons if they have been
locked in the [LOCK SETTINGS] in the [PROTECT] menu.
Press and hold the DISPLAY button for more than ve
seconds to unlock the remote. See page 54.
7

Opens and closes the OSD menu. See page 41.
8

Acts as a back button within the OSD to move to the
previous OSD menu.
Acts as an EXIT button to close the OSD menu when on the
main menu.
9

Act as navigation buttons, within the OSD menu to move the
highlighted area up or down.
0

Act as navigation buttons, within the OSD menu to move the
highlighted area left or right.
Increases or decreases the adjustment level within the
selected OSD menu setting.
!

SET: When the OSD menu is open, this button acts as a set
button when you make a selection.
POINT ZOOM: When the OSD menu is closed, this button
acts as a point zoom button. See page 40.
@

Cycles through the inputs.
The input names reect the factory preset name for the input
unless they are manually renamed in the OSD menu.
#

Increases or decreases the audio output level.
$

Increases or decreases the point zoom level. Please refer to
the Point Zoom instructions. See page 40.
*: When using with an Option Board, the function depends on which Option
Board is installed in the monitor.
