NEC MultiSync V484 User Manual

English-20
Media Player
Displays an Image and movie saved in the USB storage device or microSD memory card connected to this monitor.
Top screen of the viewer
• Select [SETTINGS] to change the media player settings.
• While “AUTO PLAY” has been set to SLIDESHOW in SETTINGS, the monitor starts performing “AUTO PLAY” by the
operation in below:
- When the Media Player top screen is displayed on, a USB storage device is connected to the USB MP (Terminal Panel
page 9) on the monitor.
- When the Media Player screen is displayed on fi rst time after powering ON the monitor in whom a USB storage device has
been connected to the USB MP on the monitor.
For starting “AUTO PLAY”, the system will automatically search both the root directory and the folders in the subsequent level in
the USB storage device and then display found still images or movies in order. The images and movies will be displayed in the
“Sorted” order.
NOTE: Only 1 USB storage device can be recognized by the viewer.
1 to 4 shared folders can be set.
When the connection to the shared folder fails, an error message is displayed and an “x” is displayed in the folder
icon. Carry out the following checks in this case.
- Is the name of the destination folder correct?
- Is the destination folder set for sharing?
- Have access rights been set in the destination folder?
- Are there any displayable fi les saved in the destination folder?
A window will appear when you press the control panel buttons while Media Player is active. You can select controlling OSD
menu or Media Player by the appeared window.
If Media Player contents are played while TILE MATRIX is active, the image play timing might have a gap within monitors.
If the monitor is set in the portrait position, please set the image that is 90° rotated.
Displayable/playable fi les
Still
Supported formats
File extension Supported
.jpg, .jpeg, .jpe Baseline, Progressive, RGB, CMYK
.png Interlace, α channel
Supported image resolution
File extension Resolution
JPEG Up to 5000 x 5000 pixels
PNG Up to 4000 × 4000 pixels

NEC MultiSync V484 Specifications

General

Power consumption (standby)	- W
Power consumption (typical)	100 W
Portrait mode	Yes
Annual energy consumption	146 kWh
Panel life	- h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	48 \
Display brightness	500 cd/m²
Display technology	LED
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Display number of colors	1.073 billion colors
Display diagonal (metric)	120.94 cm
Active display area (W x H)	1054.1 x 592.9 mm
Internal memory	1 GB
Processor cores	4
Processor model	A53
Processor family	ARM Cortex
Processor frequency	1.2 GHz
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, MOV, MP4
Internal storage capacity	16 GB
USB version	2.0
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
Purpose	-
Operating hours (hours/days)	24/7
Product color	Black
Product design	Digital signage flat panel
Bezel width (bottom)	13.2 mm
Panel mounting interface	300 x 300 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	C-tick; CE; EMC Class B; FCC; PSB; TÜV GS; UL/C-UL or CSA; VCCI
Sustainability certificates	RoHS, ENERGY STAR
RMS rated power	20 W
Cables included	AC, DVI
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	54.7 mm
Width	1086.5 mm
Height	625.3 mm
Weight	17600 g
