English-35
English
DATE & TIME Sets the date, time, and daylight saving region. Date & time must be set in order for the “SCHEDULE” function to
operate. See page 34.
NOTE: If the monitor’s main power has been turned off then two week hasn’t been turned on, DATE & TIME
setting is back to default setting and clock function stops working.
When turn on the monitor after clock function stops, the LED indicator glows red and blue. This indicates that the
clock function is back to default setting. Please set DATE & TIME again.
YEAR Confi gures the year for the real-time clock.
MONTH Confi gures the month for the real-time clock.
DAY Confi gures the day for the real-time clock.
TIME Confi gures the time for the real-time clock.
CURRENT DATE TIME Displays current date and time.
DAYLIGHT SAVING Confi gures daylight savings on or off.
NOTE: Please set TIME & DATE setting fi rst if you change DAYLIGHT SAVING setting.
DAYLIGHT SAVING If ON is selected, please set daylight saving settings below.
BEGIN MONTH Set daylight saving beginning date.
END MONTH Set daylight saving ending date.
TIME DIFFERENCE Set the time difference.
OFF TIMER Sets the monitor to go to standby after a length of time.
A time between 1 to 24 hours is available.
NOTE: SCHEDULE is not available if OFF TIMER is ON.
RESET Resets “SCHEDULE” options back to factory settings except for DATE & TIME and DAYLIGHT SAVING.
MULTI INPUT
KEEP MULTI PICTURE
MODE*
1
Allows the monitor to remain in MULTI PICTURE and TEXT TICKER mode after powering off.
When Power is returned, MULTI PICTURE and TEXT TICKER appear without having to enter the OSD.
MULTI PICTURE
MODE*
1,
*
3
NOTE: When TEXT TICKER, CLOSED CAPTION, TILEM ATRIX, MOTION in SCREEN SAVER, IMAGE FLIP
except for NONE, INPUT SUPER in INPUT CHANGE is released.
MULTI PICTURE When “OFF” is selected one picture is displayed.
When “ON” is selected several pictures are displayed.
Selects PIP or PBP.
ACTIVE PICTURE*
1,
*
2
ACTIVE When MULTI PICTURE is “OFF”, [PICTURE 1] is Active Picture. When MULTI PICTURE is “ON”, sets Active
Picture.
NOTE: This function depends on MULTI PICTURE setting.
ACTIVE FRAME Selected active picture is shown with frame.
INPUT SELECT*
1,
*
2,
*
3
Selects Multi Picture input. Press the + button or - button to select input.
NOTE: This function is not available when MULTI PICTURE is “OFF”.
When changing input signal for the active picture, after selecting an input press SET.
PICTURE SIZE*
1,
*
2,
*
4
Sets Active Picture size.
Press the SET/POINT ZOOM button to adjust picture size. Press + or CH+ to expand. Press - or CH- to reduce.
PICTURE POSITION*
1,
*
2,
*
4
Sets Active Picture location.
Pressing the + button moves Active Picture to the right, and pressing the - button moves it to the left.
Pressing the
button moves Active Picture up, and pressing the button moves it down.
PICTURE ASPECT*
1,
*
2,
*
4
Selects Active Picture frame aspect.
To change aspect ratio of the screen image, see page 19.
TEXT TICKER*
1,
*
3
NOTE: When TEXT TICKER is set, MULTI PICTURE MODE and STILL are not available.
TEXT TICKER is released if following menu is activated: MULTI PICTURE MODE, TILE MATRIX, SCREEN
SAVER, IMAGE FLIP, SUPER in INPUT CHANGE, CLOSED CAPTION.
When this function is active, POINT ZOOM and STILL are not available.
MODE Enables Text Ticker and allows you to set Horizontal or Vertical direction.
POSITION Selects the location of the Text Ticker on the screen.
SIZE Determines the size of the Text Ticker in relationship to the overall screen size.
DETECT Enables auto-detection of the Text Ticker.
INPUT SELECT Set input signal for PICTURE1, PICTURE2.
*1: This function is released when selecting SUPER in INPUT CHANGE, MOTION in SCREEN SAVER, TILE MATRIX and IMAGE FLIP except for NONE.
*2: When TEXT TICKER is active or multi picture is OFF, this function is not available.
*3: When you select OPTION for multi picture input, this function depends on which option board you use.
*4: This function is not available if PIP is set at MULTI PICTURE MODE and then PICTURE1 is set at ACTIVE PICTURE.
