NEC MultiSync V484 User Manual

English-27
English
Picture Mode
Depending on the setting at SPECTRAVIEW ENGINE (see page 33), selection of Picture mode is changed.
SPECTRAVIEW ENGINE is set to “ON”:
Selects fi ve picture modes by Picture mode in OSD menu or using Picture mode button on the wireless remote control.
Selecting Picture mode with the wireless remote control
By pressing Picture mode button, picture mode changes.
SVE-1
SVE-2 SVE-3 SVE-4 SVE-5
Selecting or changing Picture mode at Picture mode in OSD menu.
Select a setting from SVE-1 SETTING to SVE-5 SETTING at PICTURE MODE.
Select a preset item at PRESET.
Choose the Picture Mode that is most suitable for the type of content that is shown.
There are several types of mode (sRGB, Adobe
®
RGB SIM., eciRGB_v2 SIM., DCI SIM., REC-Bt709, HIGH BRIGHT, FULL,
DICOM SIM, PROGRAMMABLE).
• Each PICTURE MODE includes LUMINANCE, WHITE, GAMMA, BLACK, RED, GREEN, BLUE, COLOR VISION EMU,
UNIFORMITY and METAMERISM settings.
The type of PRESET
PRESET PURPOSE
sRGB
Standard color space used for the Internet, Windows
®
operating systems and digital cameras. Recommended setting
for general color management.
Adobe
®
RGB SIM.
Provides a standard color space used in high-end graphics applications such as professional digital still cameras and
imaging.
eciRGB_v2 SIM.
Provides a color space profi le recommended by ECI (The European Color Initiative).
DCI SIM.
Color setting for digital cinema.
REC-Bt709
Color setting for High-defi nition television.
HIGH BRIGHT
Highest brightness setting.
FULL
Native display color gamut. Suitable for use with color managed applications.
DICOM SIM.
Setting that conforms to the DICOM standard for the Grayscale Standard Display Function.
PROGRAMMABLE
For “MultiProfi ler” software or the Hardware Calibration settings by NEC Display Solutions software (some OSD
settings are disabled).
MODE PURPOSE
LUMINANCE Adjusts the overall image and screen background brightness.
Press “LEFT” or “RIGHT” to adjust.
WHITE Adjusts the white color by temperature or xy setting. A lower color temperature will make the screen reddish and a
higher color temperature will make the screen bluish. A stronger x makes the screen reddish, a stronger y makes it
greenish and weak xy makes it a bluish white.

NEC MultiSync V484 Specifications

General

Power consumption (standby)	- W
Power consumption (typical)	100 W
Portrait mode	Yes
Annual energy consumption	146 kWh
Panel life	- h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	48 \
Display brightness	500 cd/m²
Display technology	LED
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Display number of colors	1.073 billion colors
Display diagonal (metric)	120.94 cm
Active display area (W x H)	1054.1 x 592.9 mm
Internal memory	1 GB
Processor cores	4
Processor model	A53
Processor family	ARM Cortex
Processor frequency	1.2 GHz
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, MOV, MP4
Internal storage capacity	16 GB
USB version	2.0
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
Purpose	-
Operating hours (hours/days)	24/7
Product color	Black
Product design	Digital signage flat panel
Bezel width (bottom)	13.2 mm
Panel mounting interface	300 x 300 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	C-tick; CE; EMC Class B; FCC; PSB; TÜV GS; UL/C-UL or CSA; VCCI
Sustainability certificates	RoHS, ENERGY STAR
RMS rated power	20 W
Cables included	AC, DVI
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	54.7 mm
Width	1086.5 mm
Height	625.3 mm
Weight	17600 g
