NEC MultiSync V484 User Manual

English-24
NETWORK & OTHER SETTINGS
Below settings are for network setting and shared folder setting for media player.
To set the settings, press SET/POINT ZOOM button of the remote control on the [NETWORK & OTHER SETTINGS].
NETWORK SETTINGS for MEDIA PLAYER
Menu Function
IP SETTING Set these settings.
IP ADDRESS
SUBNET MASK
DEFAULT GATEWAY
DNS
DNS PRIMARY
DNS SECONDARY
NETWORK INFORMATION for MEDIA PLAYER displays what you set at NETWORK SETTINGS for MEDIA PLAYER.
SHARED FOLDER
There are two items that you can set for shared folder.
Please press SET/ZOOM button of the remote control on a setting item.
• SHARED SD CARD SETTINGS
Saved folders in the connected computer can be copied to the connected microSD memory card by controlling browser of
the connected computer.
Menu Function
ENABLE Check the checkbox to enable SHARED SD CARD SETTINGS.
USER NAME USER NAME is displayed. It is not the same name as the monitor name and it is not changeable.
PASSWORD Set password.
Please press OK to activate settings in the SHARED SD CARD SETTINGS.
If OK is not pressed, settings that you set are not activated.
• SHARED FOLDER SETTINGS.
Saved folders in the connected computer can be copied to the connected microSD memory card by controlling the monitor.
Menu Function
ENABLE Check the checkbox to enable SHARED FOLDER SETTINGS.
SHARED FOLDER Set where to be stored copied data.
USER NAME Set USER NAME which is used when connecting the monitor to the shared folder.
PASSWORD Set password.
Please press OK to activate settings in the SHARED FOLDER SETTINGS.
If OK is not pressed, settings that you set are not activated.
SHIFT NO SIGNAL
This setting is for when the monitor detected no signal input, shift the monitor to no signal status.
The monitor detects no signal after played slideshow, played media player contents, in the USB
window or in the SD CARD
window.
Menu Function
ENABLE Check the checkbox to enable SHIFT NO SIGNAL.
INTERVAL Set the time when the monitor goes into no signal after displayed detected items.
Please press OK to activate settings in the SHIFT NO SIGNAL.
If OK is not pressed, settings that you set are not activated.

NEC MultiSync V484 Specifications

General

Power consumption (standby)	- W
Power consumption (typical)	100 W
Portrait mode	Yes
Annual energy consumption	146 kWh
Panel life	- h
Pixel pitch	- mm
Response time	8 ms
Display diagonal	48 \
Display brightness	500 cd/m²
Display technology	LED
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Display number of colors	1.073 billion colors
Display diagonal (metric)	120.94 cm
Active display area (W x H)	1054.1 x 592.9 mm
Internal memory	1 GB
Processor cores	4
Processor model	A53
Processor family	ARM Cortex
Processor frequency	1.2 GHz
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, MOV, MP4
Internal storage capacity	16 GB
USB version	2.0
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
Purpose	-
Operating hours (hours/days)	24/7
Product color	Black
Product design	Digital signage flat panel
Bezel width (bottom)	13.2 mm
Panel mounting interface	300 x 300 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	C-tick; CE; EMC Class B; FCC; PSB; TÜV GS; UL/C-UL or CSA; VCCI
Sustainability certificates	RoHS, ENERGY STAR
RMS rated power	20 W
Cables included	AC, DVI
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	54.7 mm
Width	1086.5 mm
Height	625.3 mm
Weight	17600 g
