English-54
Name Setting
Click “NAME” on the left side of HOME.
MONITOR NAME Set a monitor name. The name must be 16 characters or less. The default is model name.
HOST NAME
(CONTROL)
Type in the hostname of the network connected to the monitor.
Up to 15 alphanumeric characters can be used.
HOST NAME (MP) Type in the hostname of the network to be used in the MEDIA PLAYER connected to the monitor.
Up to 15 alphanumeric characters can be used.
DOMAIN NAME Type in the domain name of the network connected to the monitor.
Up to 60 alphanumeric characters can be used.
Network Password Setting
Click “NETWORK PASSWORD” on the left side of HOME.
PJLink CLASS Set a class for PJLink.
NOTE: PJLink is a network interface standard that JBMIA established.
http://pjlink.jbmia.or.jp/index.html
This monitor is available for class1 and class2 command.
NOTIFY FUNCTION
ENABLE
Enable or disable a notifi cation of the monitor network condition. This function is only for class2.
NOTIFY ADDRESS Set IP ADDRESS to which the monitor network status will be sent. This function is only for class2.
PJLink PASSWORD Set a password for PJLink*. A password must be 32 characters or less. Do not forget your password.
However, if you forget your password, consult with your supplier.
HTTP PASSWORD Set a password for HTTP server. A password must be 10 characters or less.
HTTP PASSWORD
ENABLE
HTTP PASSWORD is required when logging in HTTP server.
Set a monitor name as USER NAME when inputting the password.
*What is PJLink?
PJLink is a standardization of protocol used for controlling devices of different manufacturers. This standard protocol is
established by Japan Business Machine and Information System Industries Association (JBMIA) in 2005.
The device supports all the commands of PJLink Class 1.
PD List Information
Click “PD LIST” on the left side of HOME.
Show the list of ID and IP address of multiple monitors that are daisy-chained.
Only the master monitor can show the list.
Memo Setting
Click “MEMO” on the left side of HOME.
Set a title and message.
TITLE A title must be 24 characters or less.
MESSAGE A message must be 240 characters or less.
MEMO PASSWORD The default is “0000”.
MEMO PASSWORD
ENABLE
MEMO PASSWORD is required when setting MEMO.
SD-CARD VIEWER setting
Click “SD-CARD VIEWER” on the left side of HOME.
Please refer to Using SHARED SD card SETTINGS (See page 25).
External Control
Connecting external device
There are two ways to connect external device to the monitor.
1. RS-232C terminal.
Using a RS-232C cable, connect an external device to the RS-232C terminal of the monitor.
2. LAN port.
Using a LAN cable, connect an external device to the LAN port of the monitor.
For the use of LAN cable, please consult your network administrator.
To Next Page
