English-32
ADJUST
AUTO SETUP
VGA (RGB) input only
Automatically adjusts Screen Size, H position, V position, Clock, Phase and White Level.
AUTO ADJUST
VGA (RGB) input only
H Position, V Position and Phase are adjusted automatically when new timing is detected.
H POSITION
VGA (RGB), VGA (YPbPr) inputs only
Controls the horizontal position of the image within the Display area of the LCD.
Press + to move right. Press - to move left.
V POSITION
VGA (RGB), VGA (YPbPr) inputs only
Controls the vertical position of the image within the Display area of the LCD.
Press + to move up. Press - to move down.
CLOCK
VGA (RGB) input only
Press + to expand the width of the image on the right of the screen.
Press - to narrow the width of the image on the left.
PHASE
VGA (RGB), VGA (YPbPr) inputs only
Adjusts the visual “noise” on the image.
H RESOLUTION*
1
VGA (RGB) input only
Adjusts the horizontal size of the image.
V RESOLUTION*
1
VGA (RGB) input only
Adjusts the vertical size of the image.
COLOR SYSTEM
VIDEO input only
The selected Color System depends on the video format of the input signal.
AUTO
NTSC Automatically chooses Color System setting based on input signal.
PAL
SECAM
4.43 NTSC
PAL-60
INPUT RESOLUTION
VGA (RGB) input only
If there is a problem with signal detection, this function forces the monitor to display the signal at the desired
resolution. After selection, execute “AUTO SETUP” if required.
If no problem is detected, the only available option will be “AUTO”.
ASPECT Select the aspect ratio of the screen image.
NOTE: When the ASPECT is DYNAMIC, the image will be changed to FULL image before IMAGE FLIP, then
start to IMAGE FLIP.
When the ASPECT is DYNAMIC or ZOOM, the image will be changed to FULL image before TILE MATRIX, then
start to TILE MATRIX. After TILE MATRIX, the ASPECT will be returned to previous ASPECT or set ASPECT
during TILE MATRIX.
If you change H POSITION and V POSITION settings with a reduced image, the image would not be changed.
ASPECT for screen saver will be full, after release screen saver, set ASPECT is activated.
This function is not available when MOTION in SCREEN SAVER is active.
When set DYNAMIC or ZOOM of the ASPECT while TILE MATRIX is active, after releasing TILE MATRIX
DYNAMIC or ZOOM will be active.
POINT ZOOM function has limitations, please refer to POINT ZOOM (See page 57).
Zoom is not available for an image with input resolution 3840 x 2160 (60 Hz).
NORMAL Displays the aspect ratio the same as it is sent from the source.
FULL Fills entire screen.
WIDE Expands a 16:9 letter box signal to fi ll entire screen.
DYNAMIC Expands a 4:3 pictures to fi ll the entire screen with non-linearity. Some of the outside image area will be cut off
due to expansion.
1:1 Displays the image in a 1 by 1 pixel format. If the input resolution is higher than a 3840 x 2160 resolution, the
image will be scaled down to fi t the screen.
ZOOM The image can be expanded/reduced.
NOTE: The expanded image, which is outside of active display area, is not shown. The reduced image may have
some image degradation.
ZOOM Maintains the aspect ratio while zooming.
HZOOM Amount of horizontal zoom.
VZOOM Amount of vertical zoom.
H POS Horizontal position.
V POS Vertical position.
*1: After setting this item individually, we recommend to run AUTO SETUP.
