NEC NEAX 2400 ICS - Figure 4-1 Mounting of the DRU Cover

CHAPTER 4 ND-45383 (E)
Page 114
Revision CD 1.0
3. MOUNTING OF COVER
This section explains the method of mounting the cover of the DRU after the installation tests have completed.
Figure 4-1 Mounting of the DRU Cover
START
Referring to Figure 4-1, mount the cover of the DRU.
When the battery is externally installed, mount the cover onto the BATT BOX ASSEM by referring to Fig-
ure 4-2.
END
DRU
