NEC NEAX 2400 ICS - Figure 3-6 Marking for the STAND ASSEM

CHAPTER 3 ND-45383 (E)
Page 34
Revision CD 1.0
3.1.2 When Installing the DRU on the Floor Using Stand Assembly (STAND ASSEM) (Option)
Figure 3-6 Marking for the STAND ASSEM
START
Marking
Drilling
END
Referring to Figure 3-6, mark the STAND ASSEM setting lo-
cations.
Referring to Figure 3-7, drill holes at the locations marked for
the STAND ASSEM.
Referring to Figure 3-8, fasten the STAND ASSEM onto the floor.
DRU
15 ( ")
3
5
500 (1' 7 ")
7
10
15 ( ")
3
5
(3 ")
9
10
100
240 (9 ")
2
5
Wall
Unit: mm
(
inch
)
