NEC NEAX 2400 ICS - Figure 3-13 Installation of the DRU (When Mounting 3 Sets of DRU Onto the 19-Inch Rack)

ND-45383 (E) CHAPTER 3
Page 41
Revision CD 1.0
Figure 3-13 Installation of the DRU (When Mounting 3 Sets of DRU onto the 19-inch Rack)
2100 mm
(7'10" inches)
1958 mm
(7'5" inches)
DRU Mounting M.T.G
19-inch Rack (IEC Spec.)
BATT BOX UNIT
(Standard)
BATT BOX ASSEM (Standard)
DRU
Note: The battery and the BATT BOX ASSEM are Locally Provided.
