NEC NEAX 2400 ICS - Figure 2-4 Example of Installation of the DRU (Floor Installation Using STAND ASSEM) (Option)

ND-45383 (E) CHAPTER 2
Page 7
Revision CD 1.0
Figure 2-4 Example of Installation of the DRU (Floor Installation using STAND ASSEM) (Option)
DRU
BATT BOX
ASSEM
DRU
STAND ASSEM STAND ASSEM
Note: The external battery and the BATT BOX ASSEM must be locally provided.
• When the battery is set inside the DRU • When the battery is installed externally
