NEC P502HL - Adjusting the Tilt (Tilt Foot)

20
2. Projecting an Image (Basic Operation)
Adjusting the tilt (Tilt foot)
Adjustingtheleftandrighttilt.
1. Turn the left and right tilt feet to adjust.
The tilt feet lengthen and shorten when turned.
The height of the projected image is adjusted by turning the left
and right tilt feet.
 Iftheprojectedimageistilted,turnoneofthetiltfeettoadjustthe
image so that it is level.
• Iftheprojectedimageisdistorted,see“6CorrectingKeystone
Distortion[KEYSTONE]”(→ page 21).
• Thetiltfeetcanbelengthenedbyamaximumof20mm.
• Thetiltfeetcanbeusedtotilttheprojectorbyamaximumof
4°.
Up
Down
Tilt foot
NOTE:
• Donotlengthenthetiltfeetanymorethan20mm/0.8".Doingsowillmakethetiltfeet’smountsectionunstableandcouldcause
thetiltfeettocomeofftheprojector.
• Donotusethetiltfeetforanypurposeotherthanadjustingtheprojector’sprojectionangle.
 Handlingthetiltfeetimproperly,suchascarryingtheprojectorbygraspingthetiltfeetorhookingitontoawallusingthetiltfeet,
coulddamagetheprojector.

