QX-S5500 Series Ethernet Switches
1
1 Product overview
1.1 Overview
QX-S5500 Series Ethernet Switches (hereinafter referred to as the QX-S5500 series) are
Layer 3 Gigabit Ethernet switching products. QX-S5500 series are designed as distribution
or access devices for intranets and metropolitan area networks (MANs). Supporting
IPv4/IPv6 dual stack and 10 GE uplink interfaces, the QX-S5500 series provide abundant
service features and can also be used for connecting server groups in data centers.
QX-S5500 series support the Intelligent Resilient Framework (IRF) technology. You can
connect multiple QX-S5500 switches through 10 GE ports to form a logical entity, thus to
establish a new intelligent network with high reliability, expandability and manageability.
QX-S5500 series include 4 models, and have the system specifications as shown in Table
1-1.
Table 1-1 System specifications of the QX-S5500 series
Item QX-S5526P-D QX-S5526P QX-S5550P QX-S5526T
Physical dimensions (H
× W × D)
440 x 300 x 43.6 440 x 360 x 43.6
GE ports
24 x 10/100/1000BASE-T
4 x100/1000BASE-X SFP
48
x10/100/1000BASE-T
4 x100/1000BASE-X
SFP
8 x 10/100/1000BASE-T
24 x100/1000BASE-X
SFP
For each Combo port, either the SFP port or the corresponding Ethernet port can be used at
a time. For details about the combo port mapping relationship, please refer to Table 1-5.
Interface card models
supported (optional)
2-port 10GE CX4 interface module (LS-CX2-T2)
2-port 10 GE SFP+ interface module (LS-SP2-T2)
1-port 10 GE XFP interface module (LS-XP1-T2)
2-port 10 GE XFP interface module (LS-XP2-T2)
1-port 10 GBASE-T interface module (LSPM3XGT2P)
Optional hot swappable
power modules
N/A
Power socket types
and quantity
1 DC power
socket
1 AC power
socket
1 AC power socket
and 1 RPS power
socket
power socket
PSR150-D1: 1 -48V DC
Power cable length 2m 3m 3m
AC power module: 3m
DC power module: 3m
AC
Rated voltage range: 100 to 240VAC ; 50/60Hz
Input voltage range: 90 to 264VAC.; dd47/63Hz
1-1
