Issue 2.0
SV9100 General Description Manual 5-13
Table 5-7 SV9100 9.5” (Base and Expansion) Maximum System Capacities – Trunks/Ports/Channels
Number of:
9.5”
Chassis
19” Chassis
System
Maximum
x 1
(CPU + 2
Slots)
x 1
(6 Slots)
x 2
(12 Slots)
x 3
(18 Slots)
X4
(24 Slots)
Number of Timeslots
1
PCM
48 104 208 312 416 416
Data
7 7 14 21 28 28
DT400/DT300 TDM (-48V)
32 80 176 272 368
Tota l 896
SLT (-28V)
32 80 176 272 368
SLT (-48V)
820446892
DT800/DT700 IP
896
Desktop Applications
(Desktop Client, Desktop Client with
Shared Services and SoftPhones)
256 Total 256
SIP/WLAN
896 Total 896
Analog Trunks (COT)
16 40 88 136 184
Tota l 400
BRI
16 40 88 136 184
PRI (1.5M)
48 96 192 288 384
IP Trunk (SIP)
400
DTMF Receivers
80 80 144 144 144 144 *2
VoIP Channels
256 256
Voice Mail Channels on CPU
16 channels 16
Modem
1 channel 1
1 = For-law countries 104 timeslots per chassis are assigned the G.711 PCM communications (e.g., voice
communications) and 7 timeslots per chassis are assigned for the Data communications (e.g., HDLC over ISDN). Thus
the simultaneous data communications are limited up to seven per chassis.
2 = An additional 64 DTMF Receivers are available when the GPZ-BS10 is installed.
If using Caller ID to analog trunks and DSP resources are set to common, DSP resources will only be used for analog
trunks and not analog stations.
