NEC Univerge SV9100 - Power Supply Consumption; Table 5-19 Power Consumption

Issue 2.0
5-22 Hardware Specifications
 Power Consumption: Base Chassis=263VA,
Expansion Chassis=263VA, total 1052VA
 Input Voltage: 90VAC to 264VAC
(Rated Voltage: 100VAC/120VAC/220VAC - 240VAC)
 Frequency: 47Hz – 63Hz (Rated frequency: 50/60Hz)
 Phase and Wire: Single Phase, 2 Line + PE Type
 Grounding Requirements: No. 14 AWG copper wire
 Feeding Voltage: D
term
/OPX/DID: -48V
SLT: 25mA / -28V
With input voltage of 120 VAC and with full load conditions:
 Output Power: Base chassis=130W, Expansion chassis=130W, total 520W
 AC Input I: Base chassis=2.19A, Expansion chassis=2.19A, total 8.76A
 VA @ 120V: Base chassis=263VA, Expansion chassis=263VA,
total 1052VA
 KWh @ AC Input I x 120V/1000: Base chassis=0.263 KWh,
Expansion chassis=0.263 KWh, total 1.052 KWh
 BTU (KWh x 3413): Base chassis=898 BTU,
Expansion chassis=898 BTU, total 3592 BTU
 A dedicated outlet, separately fused and grounded for each chassis should be
installed.
5.2 Power Supply Consumption
NOTE

Double Pole/Neutral Fusing (power supply fuses are located
at both the L and N side).
Table 5-19 Power Consumption
Chassis
Maximum
RMS
Current
Watts Used
(Idle)
Watts Used
(Maximum)
Basic Chassis – GCD-CP10 Chassis 2.19A 96 130
Basic Chassis + Expansion Chassis 4.38A 192 260
Basic Chassis + 2 Expansion Chassis 6.57A 288 390
Basic Chassis + 3 Expansion Chassis 8.76A 384 520
