Issue 2.0
1-4 Introduction to UNIVERGE SV9100
The easy-to-use adjustable footplate allows the customer to chose from a variety
of height positions that are right for them and their environment.
Only the DT300/DT400/DT700/DT800, single line telephones, cordless
telephones and wireless telephones discussed in the document can be installed
on the SV9100 system.
Several easy-to-read LCD displays are available, including a new large color
touch panel LCD.
3.2 Digital and IP Telephones
The UNIVERGE SV9100 system offers a variety of digital and IP multiline
telephones that are compatible with the system. All telephone models are offered
in both black and white.
To avoid damage to equipment, do not install the Dterm70 on the
SV9100 system. The Dterm70 (DTU/DTP) terminal uses -24V and has
no protection from the -48V power supply used by the SV9100 system.
Figure 1-4 UNIVERGE SV9100 Telephone Modular Design
