17
© by NECTA VENDING SOLUTIONS SpA 0102 Colibrì
According to the type of pre-selection set in the layout,
button "3" allows access to the sugar dose, which can be
adjusted with buttons "1" and "5"; pressing button "6" again
will release the set sugar dose.
Alternatively, button "3" indicates the available doses on
the display (sugar, extra sugar).
When pressing button "6" the current sugar dose will be
dispensed.
AUTOTEST
This function is used to check the functioning of the main
machine components.
Before carrying out this operation, remove the waste tray
and the powder containers and disassemble the coffee
unit.
When pressing button "4" the message "AUTOTEST" will
be displayed blinking.
Press button "2" to cancel the operation, confirm with
button "6" to start the autotest cycle.
In a sequence:
- the doser units are activated for 2 seconds
- the mixers are activated for 2 seconds
- a cup is released
- a stirrer is released
- (for Espresso models only) the coffee unit is rotated, a
coffee dose is ground and then released.
- (for Espresso models only) the waste tray is detected;
the machine stops until the waste tray is manually re-
inserted
- the push-button panel is checked; the machine dis-
plays the number of the button which must be pressed
and waits for this to be done before going to the next
button (number 9 corresponds to the cleaning button).
EMPTYING THE AIR-BREAK
This function is used to partially empty the air-break,
dispensing water from the milk solenoid valve for 8 sec-
onds before blocking the machine, to allow the machine to
be moved without spilling water; to restore normal func-
tioning the machine must be switched off and then on.
Before moving the machine on a long distance, especially
if involving the use of a vehicle, the hydraulic system must
be emptied manually.
DISPLAYING THE STATISTICS
Pressing button " " when the display indicates the "Dis-
play statistics" function causes the stored data to be
sequentially shown on the screen, and more precisely:
1 - single selection counter;
2 - single price counter;
3 - counter per type of coin cashed;
4 - total cash counter;
5 - failure counter.
PRINTING THE STATISTICS
The statistics described in the section "displaying the
statistics" can be printed with a RS-232 serial printer with
a Baud rate of 9600, 8 data bit, no parity, 1 stop bit,
connected to the serial port located on the push button
board (the CITIZEN I-DP 3110-24RF 230 A p/n 9210219
printer is recommended). The hardcopy printout will also
contain the machine code number and the printout pro-
gressive number.
The progressive hardcopy printout number can be reset
only by initializing the machine.
To connect the printer do as follows:
- Press button " " when the display indicates the "Print
statistics" function and the message "Confirm?" will be
displayed;
- before confirming connect and switch on the printer;
- press the confirm button “
” to start printing.
RESETTING THE STATISTICS
Press button " " when the display indicates the "Reset
statistics“ function and the message "Confirm?" will be
displayed blinking.
Press the confirm button “ ”, the message "Working" is
displayed for a few seconds and the statistics are reset.
GENERAL COUNTER
The machine stores all selections in this counter, which
cannot be reset.
This function allows reading of the counter or its display
when the machine is switched on.
Press button " " when the display indicates the "General
counter" function and the function status (ON/OFF) will be
displayed; press button " " to display the status blinking,
which can then be changed with the " "and " " buttons.
Press button " " again and the stored value will be
displayed for 3 seconds.
