Nedap AEOS Blue User Manual

Installation and Configuration | AEOS Blue and vehicle identification EN
Manual version 3 36/48
5.3 Configuring AEmon for TCP/IP ─ with Generic Message Mapper
From AEOS version 2019.1.3 onwards, the IpBadge AEbc supports the ANPR LUMO and
configuring AEmon has become easier. For instructions, see section 5.2.
To configure the AEOS Blue controller for the ANPR LUMO reader in AEmon with the Generic
Message mapper AEbc, take the following steps:
Configure the identifier type in AEmon
1. Start AEmon
2. In AEmon, create/open the configuration, including the AP7803 AEOS Blue controller, the
Generic Message Mapper AEbc, the LabelValueToString AEbc, the StringFormatter AEbc,
the InputToBadge AEbc and the StandardDoor access point (see the AEOS Access Points
and Entrances manual).
3. Right-click the
Generic Message Mapper AEbc and click Properties.
4. Adjust the settings as shown below.
(See the AEbc Message Mapper descriptions manual for more information.)
Property
Value
IO server type > IO Provider Type
Generic IP Protocol
▼
IP settings > Server event port
10000
IP settings > Incoming Protocol
Full TCP
▼
IP settings > Outgoing Protocol
Disabled
▼
Step
01
