24 V DC input connector (Audio Amplier - 2:25 only)
Power is supplied through this connector. Connect the supplied Neets mains
power adaptor with the round DC input and connect the mains cable to the
AC supply only after all other connections to the amplier have been made.
Use only the included Neets mains power adaptor to supply power to the
amplier.
12 V DC input/output connector (Preamplier only)
On the Preamplier, this connector can be used to supply power to the unit
using the included mains power adaptor. Alternatively, the connector can be
used to power external 12 V equipment from the internal PoE supply when
using the Preamplier with a PoE-enbled LAN connection.
When using the connecter as power supply to other equipment, please note
that the maximum output current is 350 mA. The output has an auto re-
settable fuse which will protect the connection from overloading when used
as a power output.
