Nektar Pacer User Manual

12 Nektar Pacer User Guide www.nektartech.com
Expression Pedal Type Data Settings
Expression pedal inputs 1 and 2 have different message types as shown in the below chart.
Type Options for Exp1/Exp2 Display Data 1 Data 2 Data 3 MIDI Channel
MIDI CC CC MIDI CC (0-127) Min (0-127) Max (0-127) 0=Global, 1-16
MIDI NRPN Coarse NRPNC Value (0-127) LSB (0-127) MSB (0-127) 0=Global, 1-16
MIDI NRPN Fine NRPNF Value (0-127) LSB (0-127) MSB (0-127) 0=Global, 1-16
Pitch Bend PB Value (0-127) Min (0-127) Max (0-127) 0=Global, 1-16
AfterTouch AFT Value (0-127) Min (0-127) Max (0-127) 0=Global, 1-16
O OFF n/a n/a n/a n/a
Setting MIDI Channel for a Step
MIDI messages can be sent on any MIDI channel from 1 to 16 or on the global MIDI channel (value=0).
• Move the [Data Encoder] until ”M CHA“ appears in the display, then press the [Data Encoder].
• Move the [Data Encoder] to select a value from 1-16 or 0 (Global MIDI Channel) and press the [Data Encoder] to accept the change.
LED Colors
A selection of LED colors is available for each of the 10 switches ([A]–[D] and [1]–[6]). How they are used and what they mean is user-con-
figurable. By default, each color represents an assignment type (see chart below). A color can be programmed for on and off states – or in-
stead of choosing different colors you can use the same color for both on/off with the off setting dimmed (A=full illumination, b=dimmed).
• Move the [Data Encoder] until ”LED“ appears in the display and press the [Data Encoder] to select it.
• Move the [Data Encoder] to scroll through the menus in the chart below and press the [Data Encoder] to select.
• Set the Value using the [Data Encoder] and press the [Data Encoder] to set it.
Chart 1
Menu Display Value Function
MIDI MIDI O/On If On, LED on and o colors are triggered by the assigned MIDI
message received via the USB MIDI port.
On Color ONCLR O, 01a/b to 12 a/b, Default Sets the color used for On/maximum value state.
O Color OFCLR O, 01a/b to 12 a/b, Default Sets the color used for O/minimum value state.
LED Number LEDNM 0-3 Sets which of up to 3 LED’s should be illuminated on the switch.
0=default, 1=bottom, 2=middle, 3=top.
Back BACK n/a Return to Control Edit top level.
Chart 2 (A=full illumination, b=dimmed)
Color No Color Default Color for Mes-
sage Type
Color No Color Default Color for Message
Type
1A / 1b Step select 7A / 7b MIDI Note
2A / 2b Preset select 8A / 8b DAW function
3A / 3b MIDI Program 9A / 9b MIDI cc
4A / 4b 10A / 10b Relay
5A / 5b MMC 11A / 11b NRPN Coarse, NRPN Fine
6A / 6b 12A / 12b
Control Edit (cont.)

Nektar Pacer Specifications

General

Type	MIDI Foot Controller
Number of Footswitches	10
Expression Pedal Inputs	2
Connectivity	USB, MIDI
Power Supply	9V DC
MIDI Ports	In, Out
