2.2. File Mount
First select one file, click”mount”, then you will enter into mounting interface, above picture is an example of one
file in mounting.
1) On the top-left corner shows mounting process, chip list---by the variation of white line, you can track
process of mounting constantly.
2) On the bottom-left corner shows some feedback during mounting process.
3) On the top-right corner shows the status of picking and picking alignment
4) On the top-right corner shows some control information：
5) Real-time air pressure of 2 nozzles
6) Placement speed, can be changed by manual during mounting
7) Continuous,this is used in one-stop smt production line, add conveyors in front and behind,
8) Auto-eject PCB once finished, when select this option, after finished mounting task, PCB will eject its
working area automatically
9) Other control information,Start&Continuous/Step/Pause(stop)/Eject PCB front/Stop
10) The machine will execute command and work constantly
Step: The machine will work one single step
Pause: The machine will stop its work instantly
Eject PCB Front: In order to catch the PCB, after PCB assembly, click this option, PCB will eject from its
feeding position. Kindly notice: After pause the machine then you can execute required command.
Exit: before click this option, you need to click “stop” first
