Chapter
USE
NEOFOLD HS
VERSION: NF.HS-07-03/2015-GB 6-3
Using the Special function 6.1.4
The special function can be used to obtain folds different from the pre-set ones of 190 or
210. the value can be set using the keyboard and can vary between a minimum of 70mm
to a maximum of 499mm. The value can be increased through millimeter steps.
In modality special the machine can execute the operation of crossfold if selected
previously, this option, renders but the possibility ineffective to use such function with
inferior formats to A3. For the inferior formats to A3 the function of crossfold must be
disabilities, acting on the appropriate push-buttons, before approaching the function
special.
Press and keep the button
190
pressed for more than three seconds
The display shows the following message
SP
, it is now possible to configure the
machine according to our needs.
Press the button
20
to set the hundreds, the display shows just one figure
2
, press the buttons or to increase or decrease the value
(adjustment range between 1 and 4).
Press the button
20
to set the decimals and millimeter units, the display shows two
figures
35
,using the buttons or increase or decrease the value
until the desired size is obtained (if the value of the hundred is set to “1” the value of
the decimals cannot be lower than 20).
Press the button again, the display shows the message “insert the sheet to fold” again,
using the usual procedure.
Press
190
for more than 3 seconds to exit the special function.
Fig. 6.7
