Neptune ProCoder User Manual

3: Wiring the Pit Set Version
To wire the pit set version, complete the steps. Figure 5
shows the components required for installation.
Figure 8: Installation Components
Figure 9: Scotchlok
Connector
1. Hold the Scotchlok™
between the index
finger and thumb
with the red cap
facing down.
2. Take one non-stripped
black wire from the
pigtail and one from
the receptacle / MIU
and insert the wires
into the Scotchlok
connector until fully
seated.
Figure 10: Seating the
Connector Wires
- 5 -

Neptune ProCoder Specifications

General

Brand	Neptune
Model	ProCoder
Category	Media Converter
Language	English
