l E-CODER and ProCoder registers
cannot be programmed while
connected together in a network.
Each register must be programmed
separately prior to making the
network connection.
l
The designations HI and LO are
Neptune designations for the high
(HI) flow or turbine side of the
compound, and the low (LO) flow or
disc side of the compound.
l The settings can also be used to
designate the primary (HI) and
secondary (LO) meters in a dual set
application.
Programming the HI Register
To complete the following steps, use the Neptune
Field Programmer to select the ProRead Program tab
for programming.
1. Select RF
Compound HI
format.
2.
Match the
Connectivity 2W.
3. Match the Dial Code
65.
4. Type the
appropriate register
ID.
Figure 17: HI Register
- 9 -
