P350 - P354E
AUTOTIMER1 / AutoTimers 2-8
NOTE 5
Available in D8x/D16x V6 and later.
PROGRAM MODE LEVEL
Installer mode or NessComms V5.3
or later.
FACTORY DEFAULT
none
RELATED OPTIONS
P121E Enable AUX1 for AutoTimers
P122E Enable AUX2 for AutoTimers
P123E Enable AUX3 for AutoTimers
P124E Enable AUX4 for AutoTimers
P145E AUX1 Pulse Time.
P146E AUX2 Pulse Time.
P147E AUX3 Pulse Time.
P148E AUX4 Pulse Time.
P390E AutoTime Warning.
P392E Enable AutoTime User Codes
P202E - P256E Extra Option 9.
Enable user codes for AutoTime.
NOTE 1. Do not use the same
AutoTimer to enable and disable user
codes. For example, use AutoTimer1
to set the Code Enable time and
AutoTimer2 to set the Code Disable
Time.
The user codes must also be enabled
for AutoTime using Extra Options for
user codes.
NOTE 2. If Open/Closing reports are
enabled a Closing Extended report
(Contact ID 464) is sent to the control
room.
NOTE 3. If Open/Closing reports are
programmed, user Codes 91 to 98
are used to identify AutoTIME arming
and disarming. AutoTime1 is code
91 then consecutively through to
AutoTIME 8 is code 98.
NOTE 4. Note that each AutoTimer
controls different AUX outputs.
STEP 1.
Set the the Time and Day Of The Week at which AutoTimer1 will activate.
TO PROGRAM
1. Press P350E - P352E. Existing value is displayed one digit at a time.
2. Press [New value] E. The new value is displayed one digit at a time.
P350E AutoTimer1 Minutes. Enter a value between 00 and 59.
P351E AutoTimer1 Hours. Enter a value between 00 and 23. (00 = Midnight).
P352E AutoTimer1 Day. Enter values between 1 and 7. (1E=Sunday). If the AutoTimer
event is intended to take place every day, then enable all days, 1E-7E.
STEP 2.
Set the Actions which will take place on the Time and Day set above.
TO PROGRAM
1. Press P353E or P354E.
2. Press 1E-8E to turn an option ON or OFF. Multiple options can be selected.
P353E
TO ENABLE AUTO-ARMING
1E Area1 Arm. Arms Area1 at the time & day set by AutoTimer1.
2E Area2 Arm. Arms Area2 at the time & day set by AutoTimer1.
3E Home Arm. Arms Home Mode at the time & day set by AutoTimer1.
Note. Option 3E enables Home Arm for AutoTimers 1 to 6 but enables Day Mode Arm for
AutoTimers 7 and 8.
TO ENABLE/DISABLE USER CODES BY AUTOTIMER
NOTE 1
4E Code Enable. User Codes enabled for AutoTime become active from the time set
above. CODE ENABLE/DISABLE allows a period to be set on selected days of the week
during which selected user codes can be used. Outside this period the codes will not work.
5E Code Disable. User Codes enabled for AutoTime are disabled at the time set above.
TO ENABLE PRE-EVENT WARNING BEEPS
6E Keypad Beeps. Turn this option on to enable the AutoTimer Warning (continuous
slow beeps). The keypad/s will beep to warn that this AutoTimer is about to begin. Keypad
beeps begin xx minutes before the AutoTimer is due to start as set by option P390E.
1. To silence the beeps during the warning period. Pressing any key on the keypad will
stop the beeps on the keypad (and the Reset output) and then start again for the final
minute with a slightly faster beep.
2. To delay the AutoTime event, enter a valid user code on its own. (The user code must
be assigned to an Area to work). This will turn off the warning beeps and the Auto Arm
for 1 hour - when the warning process will start again.
7E Reset Output Beeps. If 6E is ON, then this option also beeps the RESET output for a
much louder AutoTimer warning if required.
8E Enable AutoTimer Extension. This allows the AutoTIME Arming
NOTE 2
, Code Enable
& Disable and the Aux3, Aux4 actions to be delayed by entering a USER code during the
Warning period.
TO ENABLE AUTO-DISARMING FOR EACH AREA
NOTE 3
P354E
1E Area1 Disarm. Disarms Area1 at the time & day set by AutoTimer1.
2E Area2 Disarm. Disarms Area2 at the time & day set by AutoTimer1.
3E Home Disarm. Disarms Home Mode at the time & day set by AutoTimer1.
4E [not used]
TO CONTROL OUTPUTS BY AUTOTIMER
NOTE 4 & NOTE 5
These AUX actions will take place at the time & day set by AutoTimer1.
5E AUX1 Toggle. Changes the current state of the AUX1 output. If ON then it will turn OFF
and if OFF will turn ON.
6E AUX1 Pulse. Turns on the AUX1 output for a time period set P145E.
7E AUX2 Toggle. Changes the current state of the AUX2 output. If ON then it will turn OFF
and if OFF will turn ON.
8E AUX2 Pulse. Turns on the AUX2 output for a time period set P146E.
Note. AUX outputs must be enabled for control by AutoTimers at options P121E-P124E.
NOTE 5. These instructions cover
the programming of AutoTimer1.
The programming for AutoTimers
2 to 8 is identical but with a different
set of option numbers. See the
Options Summary on page 91 for
a full list of programming options
for each AutoTimer.
HANDY HINT.
There are two ways to turn
outputs on by AutoTimer -
depending on how long the AUX
output is to stay on.
1. If the ON period is less than 20
seconds then the Pulse Output
option can be used to get timing
periods measured in seconds.
This method only requires one
AutoTimer to be programmed.
2. For longer periods (up to a
week), a pair of AutoTimers can
be used - one to turn the AUX
ON & the other to turn it OFF.
71
NESS D8X / D16X DELUXE CONTROL PANEL – INSTALLATION MANUAL
71
AUTOMATION
FEATURES
