SPECIFICATIONS
Plastic housing dimensions ... 235w x 300h x 90d mm.
Power requirement ................17VAC or 20VDC
Quiescent current draw ......... 80mA with 1 keypad.
Rechargeable battery............. 12 volt 7.0 Amp/hour Sealed Lead Acid.
Battery charging current ........ 350mA maximum, current limited.
Dynamic battery test .............. Backup battery is tested under load, hourly and on arming.
Fuses ......................................2 Amp auto resetting / Siren output & Reset output.
500mA auto resetting / 12 volt auxiliary outputs.
200 mA auto resetting / strobe output.
INPUTS / OUTPUTS
Zones ..................................... 8 or 16 zone inputs. 2 x 24hr tamper inputs.
End of line resistor ................. Default 2200 Ohms (2.2k). Other values programmable.
Maximum keypads ................. 3.
LISTEN header ....................... Output for audio alerts and dialler listen-in.
RECEIVER header..................Connection for the Ness Radio Interface.
AUX header ............................ Multi-pin connector provides outputs Aux1, Aux2, Aux3, Aux4, 12V DC
and connection for output expander/s.
SERIAL header ....................... Serial data port for data input.output and direct connect programming
using NessComms™ software.
READER header ..................... Multi-pin port for connecting up to 3 Ness proximity access card readers.
Siren ....................................... On board siren driver with timed output .
Maximum 3 x 8 Ohm horn speakers.
Strobe ..................................... 12V DC timed output. Maximum 2 x 1 Watt strobe lights.
Reset ...................................... 12V DC timed output. Maximum 3 x 12V piezo screamers.
Equipment power output ....... 13.8V DC output for powering detectors and other equipment. Maximum
500mA.
CONTROL PANEL PACKING LIST
1 D8XD or D16XD Main board
1 Housing
1 Keypad (not supplied with all models)
1 Power supply (Australia only)
1 12V 7Ah battery (optional)
1 Dialler telephone lead
1 User manual
1 Installer manual
9 or 17 End Of Line resistors 2.2k (D8x/D16x)
1 Lead assembly for battery
1 Lead assembly for internal tamper
2 Housing cover screws
4 Circuit board standoffs
APPROVALS
EMC COMPLIANCE
EN 50130-4:1996 Part 4: Electromagnetic compatability. Electrostatic Discharge, Radiated RF
Immunity, Electrical Fast Transient/burst. Surge Immunity, Conducted RF Immunity, Voltage Dips and
Interruptions, Mains Supply Variations.
AS/NZ CISPR 22:2002- Class B, Electromagnetic Radiation, Terminal Disturbance Voltage.
EN61000-6-3:2001, Harmonic Current Emissions, Voltage fluctuations and Flicker.
TELECOM
TBR21, EU. PTC200, NEW ZEALAND TELECOM . AS ACIF S002, AUSTRALIA
SAFETY
EN60950:2000 inc Country Deviations, Safety of Information Technology Equipment
AS/NZ3260-1993 incl. AMDTS 1,2,3 &4. TS001-1997 ACA Australian Communications Authority
92
NESS D8X / D16X DELUXE CONTROL PANEL – INSTALLATION MANUAL
