CONNECTION DIAGRAMS
NESS D8/D16
CONTROL PANEL
EXTERNAL
INTERNAL
TAMP
C
STR
RESET
SIREN
RED
RED
BLACK
BLACK
N.O. TAMPER SWITCH
(761-002) Colour: BLACK
STROBE LIGHT
(NOI300)
The terminal block should
be mounted inside the
siren cover.
HORN
SPEAKER
(NOI110)
2K2
9
NESS D8X / D16X DELUXE CONTROL PANEL – INSTALLATION MANUAL
Optional Accessories for D8 & D16
Generic Detector Wiring Examples
LUX HW Detector Wiring
Siren Wiring Examples
+12V
Red
DA
TA
White
RSSI
Blue
OV
Black
100-200
Ness Radio Interface.
#
The Weigand Interface and Ness PD
both connect to the READER
header. Weigand Interface may be
temporarily disconnected to use the
Ness PD.
Blu
Brn
Grn
Wht
Red
Blk
1 2 3
106-012 Weigand
Interface.
Provides connection
for up to 3 addressable
Weigand Readers (Ness
101-014).
See page 82.
106-017 Ness PD
Portable Download
Tool. For easy on-site
copying and re-loading
of programming
options. Requires D8x/
D16x version 7.4 or later.
NESS PD
106-017
D8X / D16X
PORTABLE
DOWNLOAD
READER
#
header
READER
#
header
RECEIVER
header
The Relay Board and the Output Expander Board connect to
the Aux header but not at the same time.
External trigger to turn on the LUX
nightlight.
Pull to 0v to turn on.
Nightlight status output. Pulls low
(0v) when light is on.
Fast reacting output is low (0v)
when movement is detected.
Additional +12V terminal.
0V +12V AUX4 AUX3 AUX2 AUX1
NO C
AUX1
NC NO C
AUX2
NC NO C
AUX3
NC NO C
AUX4
NC
106-013 Relay Board.
Provides 4 relay
outputs suitable for
switching low voltage
accessories.
Connect up to one additional expander
OUT
12V In
12345678910111213141516
+
IN
106-011 Output Expander.
Provides 16 programmable
open collector outputs.
See page 54.
AUX header
AUX header
450-246
Serial Cable.
Used for two-way
serial comms or
direct connect to
a PC.
Note. Previous
D8/D16 requires
the 3 pin header
cable 450-185
SERIAL header
(4 pin)
To PC serial port
or serial-USB
converter
D8x/D16x PANEL D8x/D16x PANEL
4 wire example
6 wire example
with 24hr Tamper
D8x/D16x PANEL
ANY NESS OR GENERIC
HARDWIRED DETECTOR
NESS LUX HW
DETECTOR
DETECTOR
0V
ALARM
TAMPER
N.C.
N.C.
+12V
N.C.
N.C.
ZoneZone
TAMP
0V
CC
C
+12V
2K
2
ZoneZone
0V
CC
+12V
2K
2
0V
ALARM
TAMPER
N.C.
N.C.
+12V
N.C.
N.C.
ZoneZone
TAMP
0V
CC
C
+12V
2K2
2K2
+12V TAMPER ALARM 0V +12V
OUT
FAST SENS LIGHT
OUT IN
AUX1
AUX2
AUX3
AUX4
+12V
0V
EXAMPLE
Using Aux1 on your D8x/D16x to turn
on the the LUX HW nightlight from the
keypad or even remotely.
INSTALLER PROGRAMMING
P141E 4E should be ON.
OPERATION

on/off

menu.
* HINT. Use a 450-159 loom (cut and use one end
only into the panel's Aux header).
Or a 106-011 output expander or 106-013 relay
board can be used and wired accordingly.
