P338E 1E–8E
RELATED OPTIONS
P121E 8E, P122E 8E, P123E 8E,
P124E 8E, P151E 7E, P152E 7E,
P153E 7E, P154E 7E, P319E, P329E,
P339E
P319E, P329E, P339E
PROGRAM MODE LEVEL
Installer mode or NessComms.
RELATED OPTIONS
P318E, P328E, P338E.
READERS 1–3 OUTPUT TIME
This sets the time that the outputs selected by P318E, P328E and P338E are ON.
Range 1-24 seconds.
PROGRAMMING SEQUENCE:
P319E, P329E or P339E existing Reader Output Time is displayed one digit at a time
[ENTER NEW VALUE] E new value is displayed one digit at a time
4E ON: Reader 3 output to Aux4 (P124E 8E must also be on)
5E ON: Reader 3 output to Aux5 (P151E 7E must also be on)
6E ON: Reader 3 output to Aux6 (P152E 7E must also be on)
7E ON: Reader 3 output to Aux7 (P153E 7E must also be on)
8E ON: Reader 3 output to Aux8 (P154E 7E must also be on)
81
ACCESS CONTROL
NESS D8X / D16X DELUXE CONTROL PANEL – INSTALLATION MANUAL
