| AlphaDisc CLD user guide V2.0
37
4.3.3.2.1 Sites List
Sites List is located at the left side of the screen. It contains all owned and linked Sites.
Each list element contains the following information:
4.3.3.2.2 Site header
ELEMENT DESCRIPTION
SITE PICTURE SITE PICTURE UPLOADED BY SITE OWNER TO RECOGNIZE THE SITE.
COMMUNICATION STATUS
SMALL ICON ON THE SITE PICTURE REPRESENTS THE COMMUNICATION STATUS:
BLUE ICON – THE CONTROLLER IS CONNECTED.
GREY ICON – THE CONTROLLER IS DISCONNECTED.
SITE NAME SITE NAME GIVEN BY SITE OWNER.
FILTER TYPE FILTER(S) MODEL CONTROLLED BY THE CONTROLLER.
OPERATION MODE CONTROLLER OPERATION MODE – PRIMARY OR SECONDARY.
ELEMENT DESCRIPTION
SITE NAME SITE NAME GIVEN BY SITE OWNER.
FILTER TYPE FILTER(S) MODEL CONTROLLED BY THE CONTROLLER.
OPERATION MODE CONTROLLER OPERATION MODE – PRIMARY OR SECONDARY.
COMMUNICATION STATUS
IF THE CONTROLLER IS DISCONNECTED THE STATUS "DISCONNECTED" WILL BE SHOWN
HERE IN RED.
POWER MODE
POWER MODE IS REPRESENTED BY THE ICON:
PLUG – THE CONTROLLER IS ON AC POWER.
BATTERY – THE CONTROLLER IS ON BATTERY POWER.
INFORMATION ICON
PLACE THE CURSOR ON INFORMATION ICON TO SEE THE FOLLOWING INFORMATION:
• FW VERSION
• HW VERSION
• INSTALLATION DATE
• TOTAL FLUSH COUNTER
ALERTS ICON
THE NUMBER ON THE ALERTS ICON REPRESENTS THE NUMBER OF ACTIVE ALERTS FOR THE
SPECIFIC CONTROLLER.
