| AlphaDisc CLD user guide V2.0
38
4.3.3.2.3 Overview tab
ELEMENT DESCRIPTION
CONNECTION MODE THE CONTROLLER CONNECTION MODE – ONLINE OR OFFLINE.
LAST CONNECTION ONLY IN OFFLINE MODE. THE LAST TIME THE CONTROLLER WAS CONNECTED.
NEXT CONNECTION ONLY IN OFFLINE MODE. THE TIME OF NEXT ATTEMPT TO CONNECT TO THE CONTROLLER.
CONFIG SYNCED
ONLY IN OFFLINE MODE. INDICATES IF CONTROLLER CONFIGURATION IS UP TO DATE (LAST
CHANGES SYNCHRONIZED WITH CONTROLLER) – YES OR NO.
TIME FROM LAST FLUSH ONLY IN ONLINE MODE. THE TIME SINCE THE END OF THE LAST FLUSH CYCLE.
LAST FLUSH CAUSE ONLY IN ONLINE MODE. THE TRIGGER THAT INITIATED THE LAST FLUSH.
LAST FLUSH DP AFTER
ONLY IN ONLINE MODE. THE DP MEASURED AFTER FLUSHING. INTERVAL BETWEEN END OF
FLUSHING AND DP MEASURING IS DETERMINED BY "IGNORE DP" PARAMETER (SEE APPENDIX
A. ALPHADISC™ CLD CONTROLLER SETTINGS).
PRESSURES READINGS – INLET THE CURRENT READING OF THE FILTER'S INLET PRESSURE.
PRESSURES READINGS – OUTLET THE CURRENT READING OF THE FILTER'S OUTLET PRESSURE.
PRESSURES READINGS – DP
THE PRESSURE DIFFERENTIAL ACROSS THE FILTER; CALCULATED BY SUBTRACTING THE
OUTLET PRESSURE FROM THE INLET PRESSURE.
MANUAL FLUSHING BUTTON ONLY IN ONLINE MODE. CLICK THIS BUTTON TO START A MANUAL FLUSH CYCLE.
FLUSHING CYCLES – DIAGRAM DISPLAYS THE RATIO OF FLUSHING CYCLES STARTED DUE TO DIFFERENT CAUSES.
FLUSHING CYCLES – DP THE NUMBER OF FLUSH CYCLES STARTED DUE TO A DP EVENT.
FLUSHING CYCLES – INTERVAL
THE NUMBER OF FLUSH CYCLES STARTED DUE TO THE TIME INTERVALS PROGRAM. ALSO
COUNTS THE ANTIFREEZE PROTECTION INTERVALS FLUSHES.
FLUSHING CYCLES – MANUAL THE NUMBER OF FLUSH CYCLES STARTED DUE TO A MANUAL FLUSH BY THE USER.
FLUSHING CYCLES – PRESET THE NUMBER OF FLUSH CYCLES STARTED DUE TO THE PRESET START TIMES.
FLUSHING CYCLES – RESET
BUTTON
CLICK THIS BUTTON TO RESET THE COUNTERS TO ZERO (EXCLUDING TOTAL FLUSH
COUNTER).
REPORTS – DATA TYPE DROP-DOWN
LIST
THE DROP-DOWN LIST FOR SELECTION OF DATA TYPE TO BE DISPLAYED ON THE CHART.
REPORTS – PERIOD DROP-DOWN
LIST
THE DROP-DOWN LIST FOR SELECTION OF PERIOD FOR WHICH THE DATA WILL BE
DISPLAYED ON THE CHART.
REPORTS – CHART DISPLAYS THE DATA ACCORDING TO THE SELECTED PARAMETERS (DATA TYPE AND PERIOD).
LAST RESET DATE THE DATE OF THE LAST RESETTING OF THE COUNTERS.
